Connections for playback
You can use this digital camcorder as a VCR by connecting it to your TV for playback.
There are some ways to connect the digital camcorder to your TV. When monitoring
the playback picture by connecting the digital camcorder to your TV, we recommend
you to use house current for power source.
Connecting directly to a TV/VCR with Video/Audio input jacks
If you connect directly to a TV
Open the jack cover and connect the digital camcorder to the inputs on the TV by using
the supplied A/V connecting cable. Set the TV/VCR selector on the TV to VCR.
If you are going to connect the digital camcorder using the S video cable [a], you do not
need to connect the yellow (video) plug of the A/V connecting cable [b].
If your TV has S (S1) VIDEO IN jack and it is connected with S1 VIDEO OUT on this
digital camcorder, it turns to a wide picture automatically when you play back wide
picture recorded by this digital camcorder.
: Signal flow
TV
AUDIO IN
VIDEO IN
S (S1) VIDEO IN
S1 VIDEO OUT
VIDEO OUT
AUDIO OUT
[a]
[b]
