13
Hookups and Settings
With this hookup, you can record any channel on the cable box or satellite receiver. Be sure that
the satellite receiver or cable box is turned on.
To watch cable or satellite channel, you need to match the channel on the recorder (L1) to the
input jack connected to the cable box or satellite receiver (LINE 1 IN).
z Hints
• If your cable box or satellite receiver has an S-video jack, you can use an S-video cord (not supplied)
instead of the audio/video cord.
• If you connect an S-video cord to the LINE 1 IN jack, set “Line1 Input” of the “Line Input” to “S Video”
in the “Video” setup (page75).
A: Cable box or satellite receiver with a video/audio output
ANT IN
RL
S VIDEO
AUDIO
OUT
VIDEO
OUT
TO TV
to LINE 1 IN
DVD recorder
Audio/video cord
(not supplied)
: Signal flow
Cable box/satellite receiver
Antenna cable
(supplied)
to antenna input
S-video cord
(not supplied)
Wall
TV
,continued
