Rear
Item Name Function or control
1 S-Video input jack Connect the S-Video cable from an external video source to this jack
2 AV1 input jacks Connect the Video (Yellow), Audio Left (White), and Audio Right
(Red) cables from an external AV source to these jacks
3 AV output jacks Connect the Video (Yellow), Audio Left (White), and Audio Right
(Red) cables to an external AV device to these jacks
4 COMPONENT input jacks Connect the Y, C
B
, C
R
, Audio Left (White), and Audio Right (Red)
cables from an external AV source to these jacks
5 Antenna jack Connect the 75 ohm antenna cable from:
• an indoor antenna
• an outdoor antenna
• the cable TV cable
• the satellite cable
• the cable from a descrambler box
(
1
)
1
4
5
6
2
3
7
