OPERATION
55
TV Guide On Screen system
Overview of downloads
The information for the TV Guide On Screen system is downloaded from the
Antenna or Cable sources. To download information, it is necessary to set up
the TV Guide On Screen system in the following manner:
1. Bring up the Setup Menu
The first time you set up the HD DVR, the Setup menu is displayed automat-
ically. (See Figure 1)
After initial setup, you can bring up the Setup menu manually.
Follow the instructions on the screen.
1-a. Downloading with an Antenna.
Follow the instructions:
“Do you have cable service?” select “No”.
“Do you have a cable box?” select “No”.
1-b. Downloading with Cable.
Follow the instructions: (See Figure 2)
“Do you have cable service?” select “Yes”.
* If you have cable box.
“Do you have a cable box?” select “Yes”. Otherwise “No”.
* If you have a cable box the cable box configuration menu appears:
Select your cable box brand from the list.
Select cable box output channel: 2, 3, 4, VIDEO 1/AUX (you need to check
your cable box hardware configuration). Be sure that the HD DVR and your
cable box are linked using the cable box controller cable.
ote
In this configuration setup, the Cable box must be ON and the HD DVR OFF
for the TV Guide On Screen system to receive information.
2. Finally, the Setup Complete display appears.
Press (SELECT) to leave the TV Guide On Screen system setup menu.
(See figure 3)
3. Select Exit option to Quit. (See figure 3)
ote
TV Guide On Screen system’s program listings will normally be available
within 24 hours of initial setup.
Figure 1
Figure 2
Figure 3
