Specifications
Television System NTSC, DTV standard ATSC (1080i, 720p, 480p, 480i)
Channel Coverage Terrestrial: 2-69, Cable: 1-125
ATSC/NTSC RF Inputs Antenna (1), Cable TV (1)
(NTSC, ATSC-8VSB over Terrestrial or Clear QAM over cable)
IEEE-1394 Inputs 4 pin (i.LINK/IEEE 1394 standard) (2)
VIDEO Inputs 1.0 Vp-p 75 Ω, sync negative, RCA jack (2)
AUDIO Inputs 0 dBm more than 47 kΩ, RCA jack (L, R) (2)
DVI Output DVI-HDTV Out (1), DVI-D Single Link connector
1080i, 720p, 480p digital RGB
Component Video Output Component Out (1 Set), Standard RCA type Jack connectors
1080i, 720p, 480p, 480i YPbPr
RGB Output RGB Out (1), 15-pin connector
S-Video Output S-Video Out (1), 4-pin Mini-DIN
480i Y/C
Video Output Video Out (1), Standard RCA type Jack connector
480i Composite
Digital Audio Output Optical (Dolby AC-3 output)
Analog Audio Output Audio Out (2) (Fixed Output Level or Variable Output Level)
Authorized Service Port 9-pin Serial Port (1)
Hard Disk Drive 120G Bytes
Recording Time About 12 hours (HD format), about 23-119 hours (SD format),
Dimension (W x H X D) 17 x 3 x 12.8 inches (430 x 76.5 x 326 mm)
Weight 7.7 lbs (3.5 kg)
Power Requirements AC 120V, 60Hz
Power Consumption 35W
Humidity 30 to 99 percent non condensing
Storage Temperature -4 to 140 degrees Fahrenheit (-20 to 60 degrees Celsius)
Operating Temperature 32 to 122 degrees Fahrenheit (0 to 50 degrees Celsius)
Video cable . . . . . . . . . . . . . . . . . .1
Audio (L/R) cable . . . . . . . . . . . . .1
Component (YPbPr) cable . . . . . .1
Remote Control . . . . . . . . . . . . . .1
Batteries (size AA) . . . . . . . . . . . .2
• Design and specifications are subject to change without prior notice.
Input/Output
Environment
Accessories
