Front Panel Controls
Remote Control Sensor
Receives signals from the remote control.
Arrow Buttons (
3
/
4
/
1
/
2
)
Navigate on-screen menus and adjust system settings and preferences.
Use the arrow keys to move to a menu option and then use the SELECT button to access it.
If no menu is displayed, the LEFT/RIGHT arrows control the volume setting and the
UP/DOWN arrows select channels.
Power
Turns the HD DVR on and off.
Display Window
EXIT
Clears all on-screen displays and returns to
normal viewing from any menu.
SELECT
If the main menu is displayed, pressing the SELECT button will activate
the selected MENU option. If the SELECT button is pressed while you
are in normal viewing, the channel banner will be displayed.
MENU
Shows the main menu on the screen. You can return to
normal viewing by pressing the EXIT button.
GUIDE
Shows station and program information on the screen.
To remove the banner, press the button again.
DISPLAY FORMAT
Sets the output resolution to 1080i, 720p, 480p, or 480i formats and
chooses the correct display format for your TV. (Refer to page 23.)
RECORD
Activates Instant Timer Recording.
To stop recording, press the button again.
