Magnavox MRV640 DVD Recorder User Manual



16
Connecting only with the RF coaxial cable
USE THIS CONNECTION IF YOUR TV ONLY HAS A SINGLE ANTENNA IN JACK AND
DOES NOT HAVE ANY AUDIO/VIDEO JACKS. Please observe that you must set the TV to
the RF Input channel (channel 3 or 4 as with a VCR).
Have the following cables ready:
an RF coaxial cable (1, supplied), and a power cable (2, supplied).
1
Switch off your TV.
2
Remove the antenna or Cable TV signal from the antenna input
jack of the TV. Insert it into the ANTENNA IN jack at the back
of the DVD recorder.
3
Connect one end of the supplied RF coaxial cable to the TV
OUT jack at the back of the DVD Recorder and connect the
other end to the antenna input jack on TV.
4
Connect the supplied power cable to the mains jack
4MAINS at the back of the DVD Recorder and to a power
supply.
The most important features of the DVD Recorder will appear
on the display.
After the initial installation is completed, this function will be
switched off. To switch on this function again, read in the section
'Standby' in the chapter 'User preferences'.
5
Press STANDBY-ON m on the recorder. 'IS TV ON?' will
appear on the display.
6
Switch on your TV and select the channel normally used for
DVD or VCR playback on your TV. Choose channel 3 or 4.
How do I switch the Recorder between channel 3 and 4?
The factory setting is for channel 3. However, if you would like to
switch to channel 4, proceed as follows:
1 Hold 4 on the remote control while 'IS TV ON?' is displayed.
2 'C04' (channel 4) will appear on the display.
3 If you want to switch back to channel 3, hold 3 .'C03' (channel 3)
will appear on the display.
?
Connecting the DVD Recorder
