6
-
2. Set-up
2.1 Installation
To install DX-PC25EA, first start SETUP.EXE contained in the provided CD. Follow a series of
instructions that appears on the screen, and the software will be installed automatically.
The default directory for installation is C:/Program Files/DX-PC25EA.
2.2 Uninstallation
To uninstall DX-PC25EA, display the [Add or Remove Programs] dialog box by selecting from
[Control Panel] and select DX-PC25EA to delete. Alternatively, select the [Uninstall DX-PC25EA]
command from the [Start] menu and follow a series of instructions that appears on the screen.
2.3 Starting and exiting
DX-PC25EA is registered in the [Start] menu after the completion of installation. To start the pro-
gram, select DX-PC25EA from the [Start] menu, and the main window will appear on the screen.
To exit the program, go to the [File] menu and select [Exit].
Note:
- Operation is not always guaranteed under any environment that satisfies the system
requirements above.
1.3 Compatible DVR
- DX-TL2530E
- DX-NT430E
Note:
- This manual describes operation of 16-ch digital recorder.
- With 4-ch digital recorder such as DX-NT430E, this software may not operate in a manner
consistent with descriptions herein regarding the number of channels (or number of screens).
For example, the [4x4] and [3x3] buttons don’t work.
- With media recorded by a digital recorder that has no multiplexer, the multiplexer function (or
function related to the [Camera] command of the [View] menu) doesn’t work.
