26
Connecting the DV-SP506
—Continued
■
HDMI Audio Output setting set to 2ch PCM
Notes:
• The 2-channel D.MIX/FRONT output signal is the same as Multichannel.
• The D.MIX/FRONT 1 and 2 outputs output the same signals.
■
HDMI Audio Output setting set to Off
Notes:
• The 2-channel D.MIX/FRONT output signal is the same as Multichannel.
• The D.MIX/FRONT 1 and 2 outputs output the same signals.
Audio output
HDMI OPTICAL & COAXIAL
Analog output
Disc type Audio format
Multichannel
*1
Audio CD
44.1 kHz PCM
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 2ch
DVD-Video
96 kHz PCM
S/PDIF (48 kHz) S/PDIF (48 kHz) 2ch
48 kHz PCM
S/PDIF (48 kHz) S/PDIF (48 kHz) 2ch
Dolby Digital, DTS
S/PDIF (48 kHz) S/PDIF (48 kHz) 6ch
DVD-Audio
2ch 176.4/192 kHz
S/PDIF (44.1/48 kHz) S/PDIF (44.1/48 kHz) 2ch
6ch 88.2/96 kHz
S/PDIF (44.1/48 kHz) S/PDIF (44.1/48 kHz) 6ch
6ch 44.1/48 kHz
S/PDIF (44.1/48 kHz) S/PDIF (44.1/48 kHz) 6ch
SACD
Multichannel
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 6ch
*2
2-channel
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 2ch
*2
CD area
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 2ch
*1 Changes depending on the following settings: Subwoofer, Front Speaker, Center Speaker, Surround Speaker, Dolby Pro Logic.
*2 Analog audio is converted to PCM.
Audio output
OPTICAL & COAXIAL Analog output
Disc type Audio format Down Sample Off Down Sample On
Multichannel
*1
Audio CD
44.1 kHz PCM
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 2ch
DVD-Video
96 kHz PCM
S/PDIF (96 kHz) S/PDIF (48 kHz) 2ch
48 kHz PCM
S/PDIF (48 kHz) S/PDIF (48 kHz) 2ch
Dolby Digital, DTS
Bitstream
*2
Bitstream
*2
6ch
DVD-Audio
2ch 176.4/192 kHz
No output S/PDIF (44.1/48 kHz) 2ch
6ch 88.2/96 kHz
S/PDIF (88.2/96 kHz) S/PDIF (44.1/48 kHz) 6ch
6ch 44.1/48 kHz
S/PDIF (44.1/48 kHz) S/PDIF (44.1/48 kHz) 6ch
SACD
Multichannel
No output S/PDIF (44.1 kHz)
*3
6ch
2-channel
No output S/PDIF (44.1 kHz)
*3
2ch
CD area
S/PDIF (44.1 kHz) S/PDIF (44.1 kHz) 2ch
*1 Changes depending on the following settings: Subwoofer, Front Speaker, Center Speaker, Surround Speaker, Dolby Pro Logic.
*2 When the Digital Audio Out setting is set to PCM, the signal is converted to PCM.
*3 When the SACD Audio Setup setting is set to DSD, nothing is output by the OPTICAL and COAXIAL outputs.
