14
Changing TV channels or external sources
in left, right, PIP or Multipip screen
Press the
-P+ key or the 0 key or the digit
keys in order to change the TV channels or
external sources in the highlighted screen.
Scan PIP 3, PIP 8 or PIP 12
Navigate to the lowest PIP to display and press
the cursor down to display a following series
of PIP screens.
Define the position of the single PIP screen
& Select a Dual screen mode with a single PIP
screen.
é Press the cursor down to highlight the PIP
screen. A PIP menu appears with which you
can define the position of the PIP screen.
Note:When the PIP menu is timed out, press the
OK key to make it reappear.
“ Press the cursor down again to select
Position.
‘ Press the OK key or the cursor right to
activate.
( Use the cursor keys to define the position of
the PIP screen.
§ Press the OK key. The PIP menu reappears.
è Press the cursor up twice to highlight the main
screen again and press the
OK key to switch
off the menu.
On-Screen information
The highlighted On-Screen information,which
appears when changing channels, always refers
to the active screen.
Dual screen / PIP / Multipip
Press the b key to switch on Dual screen or one of the PIP
modes according to the format selection mode in the Dual screen
format list in the General menu. See Setup, General, p. 8.
Press the b key again.The screen that has a yellow border will
become the full main screen picture.
Notes:
- Continuing to hold the b key down will cycle the TV through the
various formats (Dual screen, Large PIP, Medium PIP, Small PIP, PIP 3,
PIP 8 or PIP 12) launching a new format after each second the key is
held down.After standby of the TV, the preference as set in the Setup,
General menu is used.
- It is not possible to display a VGA or HD source in a Dual screen/PIP
screen.
-When Dual screen mode is selected, two picture formats are supported:
Full screen or 4:3 letterbox picture format (vertical squeeze).
- Audio from the right screen or the PIP plays to the headphones.
B
b
¬
+
-
V
+
-
P
v
b
i
0
h
q
Select
VCR DVD SAT AMP CD
MENU
OK
123
456
789
0
Ò
®
‡π
†
Active Control
S
®
®
®
®
æ
b
Display options
- Press the cursor right to highlight the right screen.
- Press the cursor down to highlight the single (large, medium or small) PIP screen.
- Press the cursor right to enter the Multipip screen and then use the cursor keys to navigate through
the PIP screens and to highlight a PIP screen.
Dual screen
REC
PIP 3 PIP 8
PIP1 PIP1 PIP5
PIP2
PIP3
PIP 12
PIP1 PIP2 PIP3
PIP5 PIP6 PIP7
PIP9 PIP10 PIP11 PIP12
PIP8
PIP4
PIP2 PIP6
PIP3 PIP7
PIP4 PIP8
o
œ
Position
PIP
REC
