2
Preparation
& Place the receiver box wherever you want, but
make sure that air can circulate freely through
the ventilation slots. Do not install the receiver
box in a confined space such as a book case or
a similar unit.
To prevent any unsafe situations, no naked
flame sources, such as lighted candles, should
be placed on or in the vicinity.Avoid heat,
direct sunlight and exposure to rain or water.
The equipment shall not be exposed to
dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on it.
é Connect the supplied aerial cable 1 and the
VGA cable with trailing audio cinch connectors
2 as shown in the inside frontcover of this
handbook. Make sure all screws of the cable
2 are tightened well.
TV receiver box with speakerless monitor:
In case you connect your TV receiver box with
a speakerless monitor, and without having
connected an audio receiver,all references
made in this instruction book to sound
reproduction, volume control, and audio
connections, are not applicable (except for a
headphone connection).
The keys on the remote control referring to
sound have no function either.
“ To connect your computer,see the separate
supplied instruction manual with your monitor.
To connect other peripherals, see p. 19.
If you dispose of a Cinema Link combination
(Cinema Link Audio receiver and/or Cinema
Link video recorder and/or DVD player), see
the separate supplied instruction manual.
In order to obtain the best result, please use
only the supplied antenna cables between the
receiver box and videorecorder,and between
videorecorder and antenna connector.
‘ Insert the mains cord supplied 3 into the
mains at the back of the monitor and the mains
cord 4 at the back of the receiver. Put both
in the wall sockets.
( Remote control: Insert the 2 batteries
supplied (Type R6-1,5V).
The batteries supplied do not contain the heavy
metals mercury and cadmium. Please check on how
to dispose of exhausted batteries according to local
regulations.
§ Switch the TV on :Press the power switch B
at the right side of the monitor and the one on
the front of your receiver box.An indicator on
the front of the TV lights up and the screen
comes on. If the TV is in standby mode, press
the
-P+ keys or the red B key on the remote
control.
2
1 m
min.
