INITIAL SETTINGS (cont.)
Results of Auto Set Up/Preset Download appearing on the front display panel
If both Auto Channel Set and Auto Clock Set have been performed successfully, the
correct current time is displayed.
Turn on the TV and select its AV mode, then make sure that all necessary stations have been stored
in the unit’s memory by using the PR +/– button(s).
● If station names (ID –
੬ pg. 103) have also been stored in the unit’s memory, the station name
will be displayed at the top right corner of the TV screen for about 5 seconds when the unit is
tuned to a different station.
● If you want to set the tuner manually such as to add or skip channels, to change channel
positions, or to set or change station names, see pages 99 – 103.
If Auto Channel Set has succeeded but Auto Clock Set has not, “PR 1” (channel
position) is displayed.
OR
If both Auto Channel Set and Auto Clock Set have failed, “– –:––” is displayed.
A Turn on the TV and select its AV mode, then make sure that all necessary stations have been
stored in the unit’s memory by using the PR +/– button(s).
● If station names (ID –
੬ pg. 103) have also been stored in the unit’s memory, the station name
will be displayed at the top right corner of the TV screen for about 5 seconds when the unit is
tuned to a different station.
● If you want to set the tuner manually such as to add or skip channels, to change channel
positions, or to set or change station names, see pages 99 – 103.
B Perform “Clock Set” on page 104.
NOTE:
After making sure the cables are connected properly, turn off the unit’s power once, then turn the
unit’s power back on again.
The Country Set display appears on the TV screen; perform “Auto Set Up” on page 19 or “Preset
Download” on page 21 again.
IMP
O
RTANT:
● To check if the Guide Program numbers have been set correctly, perform the SHOWVIEW Timer Programming. (੬ pg. 54)
● In certain reception conditions, station names may not be stored correctly, and auto Guide Program Number Set may not work
properly. If the Guide Program numbers are not set properly when you timer-record a TV programme using the S
HOWVIEW
system, the unit will record a TV programme of a different station. When programming the timer using the S
HOWVIEW system, be
sure to check the desired channel is selected correctly. (
੬ pg. 54, “SHOWVIEW
®
Timer Programming”)
● Your unit memorizes all detected stations even if reception of some of them is poor. You can delete those stations with an
unacceptable picture. (
੬ pg. 100, “Delete A Channel”)
INFORMATION
Language for the on-screen display
Auto Set Up also selects the language automatically for the on-screen display depending on the Country setting you have made in
step B on page 19 (unless you have selected BELGIUM or SUISSE), as shown below.
If you want to change the language setting manually, see “On-screen Language Set” on page 24.
Just Clock
Your unit is equipped with the Just Clock function which provides accurate time keeping through automatic adjustments at regular
intervals, by reading data from a PDC signal. If you want to take advantage of this function, simply set it to “ON”. (
੬ pg. 104, “Just
Clock”)
SUOMI
]
SUOMI DANMARK
]
DANSK NEDERLAND
]
NEDERLANDS
PORTUGAL
]
ENGLISH ÖSTERREICH
]
DEUTSCH GREECE
]
ENGLISH
DEUTSCHLAND
]
DEUTSCH CESKÁ REPUBLIKA
]
ENGLISH OTHER WESTERN
]
ENGLISH
POLSKA
]
ENGLISH ITALIA
]
ITALIANO OTHER EASTERN
]
ENGLISH
NORGE
]
NORSK MAGYARORSZÁG
]
ENGLISH
SVERIGE
]
SVENSKA ESPAÑA
]
CASTELLANO
