7
AUDIO
OUT
(VARIABLE)
L
R
REMOTE
CONTROL
Using the wired remote control mode
Connect the included remote control cable to the remote
control unit's "REMOTE CONTROL" terminal.
When the cable is connected, the mode automatically
switches to wired remote control.
When the wired remote control mode is used, the remote
control unit can be operated even if no batteries are loaded.
POWER
RGB/PC VIDEO DVD/HD
CURSOR
CONTRAST
BRIGHTCOLOR
VOLUME
WIDE DISPLAY OFF TIMER
MUTE
TINT
SHARPNESS
POSITION / CONTROL
VISUAL CONTROL
OK
MENU
BACKLIGHT SYSTEM
REMOTE CONTROLLER
RD-327
Remote Control Cable
To Remote Jack
POWER/STANDBY
INPUT SELECT VOLUME
30˚ 30˚
Approx.
7m/ 23ft
Operating Range
* Use the remote controller within a distance of about 7 m
/ 23ft. from the front of the monitor's remote control sen-
sor and at a horizontal angle of within 30°.
* The remote control operation may not function if the
monitor's remote control sensor is exposed to direct sun-
light or strong artificial light, or if there is an obstacle
between the sensor and the remote control unit.
Handling the remote controller
• Do not drop or mishandle the remote control unit.
• Do not get the remote control unit wet. If the remote
gets wet, wipe it dry immediately.
• Avoid heat and humidity.
• When not using the remote control unit for a long pe-
riod, remove the batteries.
• Do not use new and old batteries together, or use differ-
ent types together.
• Do not take apart the batteries, heat them, or throw them
into a fire.
• When using the remote control unit in the wireless con-
dition, be sure to unplug the remote cable from the RE-
MOTE CONTROL terminal on the monitor.
