75
RQTV0141
Specifications (common to DMR-ES45V and DMR-ES46V)
Note
Specifications are subject to change without notice.
Mass and dimensions shown are approximate.
≥Useable capacity will be less (SD Memory Card).
Power supply:
AC 120 V, 60 Hz
Power consumption:
Approx. 29 W
Standby mode: (Display ON) Approx. 3.2 W
(Display OFF) Approx. 3.0 W
Recordable discs:
DVD-RAM: Ver. 2.0
Ver. 2.1/3X-SPEED DVD-RAM Revision 1.0
Ver. 2.2/5X-SPEED DVD-RAM Revision 2.0
DVD-R: for General Ver. 2.0
for General Ver. 2.0/4X-SPEED DVD-R Revision 1.0
for General Ver. 2.x/8X-SPEED DVD-R Revision 3.0
for General Ver. 2.x/16X-SPEED DVD-R Revision 6.0
for DL Ver. 3.0
for DL Ver. 3.x/4X-SPEED DVD-R for DL Revision 1.0
DVD-RW: Ver. 1.1
Ver. 1.1/2X-SPEED DVD-RW Revision 1.0
Ver. 1.2/4X-SPEED DVD-RW Revision 2.0
+R: Ver. 1.0
Ver. 1.1
Ver. 1.2
for DL Ver. 1.0
+RW: Ver. 1.1
Ver. 1.2/4X-SPEED
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours or 8 hours
Playable discs:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format, DVD Video Recording format
+R
+R DL (Double Layer)
+RW
DVD-Video, DVD-Audio, CD-Audio (CD-DA), Video CD
CD-R/CD-RW (CD-DA, Video CD, MP3, JPEG)
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification:
Class 1 LASER Product
Wave Length: 780 nm (CDs)
662 nm (DVDs)
Laser Power: No hazardous radiation is emitted with the
safety protection
Television system:
TV system: NTSC system, 525 lines, 60 fields
Antenna reception input:
TV Channel: VHF: 2 ch to 13 ch
UHF: 14 ch to 69 ch
CATV Channel: 5A & A-5 ch to EEE ch
Quick Start for Recording (Quick Start : ON)
1 Sec. Quick Start for Recording on DVD-RAM
°
° From the power off state, recording on DVD-RAM starts about 1 second
after first pressing the Power button and then sequentially pressing the
REC button (Quick Start Mode).
Video system:
Recording system: (for DVD)
MPEG2 (Hybrid VBR)
Input: LINE (pin jack)k2 1.0 Vp-p; 75 ≠
S connectork2 Y: 1.0 Vp-p; 75 ≠
C: 0.286 Vp-p; 75 ≠
Output: (for DVD PRIORITY)
LINE (pin jack)k2 1.0 Vp-p; 75 ≠
S connectork2 Y: 1.0 Vp-p; 75 ≠
C: 0.286 Vp-p; 75 ≠
Component video output: (for DVD PRIORITY)
Y, P
B, PRk1 Y: 1.0 Vp-p; 75 ≠
(480i/480p) P
B: 0.7 Vp-p; 75 ≠
P
R: 0.7 Vp-p; 75 ≠
Audio system:
Recording system: (for DVD)
Dolby Digital (2 ch)
Linear PCM (XP mode 2 ch)
Analog Input: LINE (pin jack)k2
Reference input: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Input impedance: 22 k≠
Analog Output: (for DVD PRIORITY)
LINE (pin jack)k2
Reference output: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Output impedance: 1 k≠
(Load impedance: 10 k≠)
Number of channels: (for DVD)
Recording: 2 channels
Playback: 2 channels
Number of track: (for VHS)
HiFi: 2 track
Normal: 1 track
Digital Output: (for DVD PRIORITY)
Digital audio optical output connectork1
(PCM, Dolby Digital, DTS)
VHS:
Recording format: VHS Video Cassette System Standard with FM audio
Heads: 4 Helical Scan Heads for Video
2 Helical Scan Heads for FM audio
1 Fixed Head for Normal audio
Tape speed/Recording time:
SP: 33.35 mm/s, 120 min (with T-120 cassette)
EP: 11.12 mm/s, 360 min (with T-120 cassette)
FF/REW time: FF/REW: Approx. 60 s (with T-120 cassette)
Jet REW: Approx. 43 s (with T-120 cassette)
HDMI Output: 19 pin typeAk1
HDMI Ver. 1.2a (EDID Ver. 1.3)
DV Input: IEEE 1394 Standard, 4 Pink1
SD Card Slot:
Still picture (JPEG, TIFF):
SD Memory Card Slot 1 pc
Compatible media: SD Memory Card
°, MultiMediaCard
° includes miniSD™ Cards (A miniSD™ adaptor
needs to be inserted)
Format: FAT12, FAT16
Image File Format: JPEG conforming DCF (Design rule for
Camera File system), TIFF (Uncompressed
RGB chunky), DPOF Compatible
Sub sampling 4:2:2 or 4:2:0
Number of pixels: Between 34k34 pixels and 6144k4096 pixels
Thawing time: Approx. 3 sec (6M pixels, JPEG)
Regional Code: # 1
Clock unit: Quartz-controlled 12-hour digital display
Operating temperature range:
5 oC to 40 oC (41 oF to 104 oF)
Operating humidity
range
:
10% to 80% RH (no condensation)
Dimensions: Approx. 430 mm (W)k84 mm (H)k343 mm (D)
[Approx. 16
15
/
16
q (W)k3
5
/
16
q (H)k13
7
/
8
q (D)]
Mass: Approx. 5.4 kg (Approx. 11.9 lbs)
Product Service/Specifications
