Basic settings
How to set 36
Titles for each camera can be up to 10 characters.
1
Display the <TITLE SET> screen as explained in
"Displaying the basic settings screen" (P34).
The monitor shows live video, and the <TITLE SET>
screen is displayed.
2
Enter a title for camera 3.
Example: Display HALL-1F
1 Press camera selection button 3, and then turn
the S-dial clockwise.
The first dash ("_") of the title setting starts blinking.
2 Turn the J-dial, select "H", and then turn the
S-dial clockwise.
When "H" is accepted, the cursor moves to the next
position.
Repeat the same procedure to enter the title.
Modifying the title
Turn the S-dial to make the desired letter blink, and
then use the J-dial to modify it.
3
Press the EXIT/OSD button when the settings are
complete.
☞ Setting conditions
Set the start and end time for Sunday (SUN) using the
<TIMER SET>, and then switch the "SET" to "ON". (P51)
1
Display the <HOLIDAY SET> screen as explained in
"Displaying the basic settings screen" (P34).
The <HOLIDAY SET> screen appears and the cursor
moves to "1".
2
Enter the date to be set as a holiday.
Example: October 17
1 Turn the S-dial clockwise, and use the J-dial to
set "17" (day).
2 Turn the S-dial clockwise, and use the J-dial to
set "10" (month).
Repeat the same procedure to enter all the
numbers.
3
Press the EXIT/OSD button when the settings are
complete.
C Title setting
MENU
(J)
(S)
3.TITLE SET
1.INITIAL SET
<MAIN MENU>
<INITIAL SET>
<TITLE SET>
CAMERA NO.03
--------
03
CAMERA NO.03
--------
03
(S)
CAMERA NO.03 H
-------
03
CAMERA NO.03 HALL-1F
---
EXIT/OSD
D Holiday setting
<TIMER SET>
WEEK START STOP PROGRAM FPS SET
SUN 08:00 18:00 OFF 12.5 FPS ON
MON --:-- --:-- OFF 12.5 FPS OFF
TUE --:-- --:-- OFF 12.5 FPS OFF
OSO
MENU
(J)
(S)
<HOLIDAY SET>
1. ----- 11. -----
2. ----- 12. -----
3. ----- 13. -----
4. ----- 14. -----
5. ----- 15. -----
6. ----- 16. -----
7. ----- 17. -----
8. ----- 18. -----
9. ----- 19. -----
10. ----- 20. -----
4.HOLIDAY SET
1.INITIAL SET
<MAIN MENU>
<INITIAL SET>
<HOLIDAY
1. -----
2. -----
3. -----
4. -----
5. -----
<HOLIDAY SET>
1. 17-10 11. -----
2. ----- 12. -----
3. ----- 13. -----
4. ----- 14. -----
5. ----- 15. -----
EXIT/OSD
