Specification
Others
Power requirement during operation
??.?W
Power requirement at standby
?.?W (Eco mode: off)
?.?W (Eco mode: on)
Power supply
230V AC, 50/60 Hz
Mass
?.?kg
External dimension
Width 430 x Height 69 x Depth 316mm
Tuner
System: Frequency synthesizer
Channel coverage:
PAL I VHF: A-J, 11, 13, E2-E12
UHF: E21-E69
CATV: X, Y, Z, S1-S41, 1-53
(48MHz to 464MHz, 8MHz steps)
Aerial input/output terminal
VHF/UHF: 75, IEC Connector
Signal system
Standard PAL Colour TV system
Laser
Semiconductor laser, Wavelength: 650nm/780nm
Format
DVD-VR format
DVD-Video format
Image recording system
MPEG2
Sound recording system
Dolby Digital M1, M2, Linear PCM
VIDEO input
1.0Vp-p (75), Sync signal negative,
Pin jack x 1 system, 1 in front
SCART socket x 2 at rear
VIDEO output
1.0Vp-p (75), Sync signal negative,
Pin jack x 1 system, 1 at rear
SCART socket x 2 at rear
S-VIDEO input
(Y) 1.0Vp-p (75), Sync signal negative,
(C) 0.286Vp-p (75), 1 in front
SCART socket x 1 at rear
S-VIDEO output
(Y) 1.0Vp-p (75), Sync signal negative,
(C) 0.286Vp-p (75), 1 at rear
Mini DIN4 Pin x 1 system
SCART socket x 1 at rear
COMPONENT output (Y, PB, PR)
Y output (green), 1.0Vp-p (75),
Sync signal negative, Pin jack x 1 system
P
B, PR output (blue, red), 0.7Vp-p (75),
Pin jack x 1 system each
RGB input
(R) 0.7Vp-p (75)
(G) 0.7Vp-p (75)
(B) 0.7Vp-p (75)
SCART socket x 1 at rear (AV1 only)
RGB output
(R) 0.7Vp-p (75)
(G) 0.7Vp-p (75)
(B) 0.7Vp-p (75)
SCART socket x 1 at rear (AV1 only)
AUDIO input
2.0V (rms), 22k or above, pin jack
(L, R) x 1 system
1 in front
SCART socket x 2 at rear
AUDIO output
2.0V (rms), 2.2k or below, pin jack
(L, R) x 1 system
2 at rear
SCART socket x 2 at rear
