Programming a recording (REC MENU) (Continued)
Recording
Deleting a timer program
The maximum timer program capacity is 32. Any new
program will be rejected if the recorder is full. To enter a
new program, you must cancel an existing one.
1) Press MENU.
2) Press
/ to select “Timer recording”, then
press ENTER.
3) Press
/ to select a timer program you want
to delete.
4) Press QUICK MENU.
The Quick Menu appears.
5) Press
/ to select “Program cancel”, then
press ENTER.
Check the message, then delete the entry.
Note
•You cannot delete a timer program while another is
executed.
To stop a programmed recording
1) Select the recording drive by pressing HDD or
DVD twice.
2) Press
on the front panel twice.
When you press the
button once, a message
appears. While the message is displayed, press the
button once again.
Note
• If you press the STOP button on the remote control, a
message appears. Select “Yes”, then press the ENTER
button.
Checking the remaining volume
1) On REC MENU Timer Programming, press
QUICK MENU.
2) Press
/ to select “Disc budget calculation”
then press ENTER.
The Disc budget calculation menu appears.
3) Press / to select a timer program, then
press ENTER.
The recorder calculates on a bar graph how much
a specific program (identified by a check mark) will
occupy on the disc.
Pressing the ADJUST button can display or remove
the check mark.
4) Correct the parameters of the timer program if
necessary.
(Skip to step 6 if you do not need this.)
Select an item you want to modify and press the
ENTER button. The item will be ready to be altered.
(When “High rate save” is set to “On”, “Pict.” cannot
be changed.)
Press the ADJUST button to modify. When
complete, press the ENTER button.
5) Press MODE.
Program modification is registered.
6) Press EXIT to exit the GUI.
Notes
• The nearest 48 programs are calculated at a time.
• While the recorder is preparing for or executing a
programmed recording, any program modification cannot
be registered. Only programs which will start after 5
minutes or later can be modified.
•Available disc volume is not displayed for a DVD-R/RW
disc on which DVD-Video finalize process was executed.
e.g.
10/23(Su)17:50
Timer Programming
REC
MENU
Ch Date Start End Pict.
Audio
Page
1/
1
1
10
42
4
-10/30(Su)
11/16(We)
11/19(Sa)
11/26(Sa)
7:00 8:30
-9:30 10:00
-10:30 11:30
- 8:30 11:30
MN 6.6
HDD
HDD
HDD
D/M2
MN 6.6
D/M2
LP 2.2
D/M1
SP 4.6
D/M2
DVD
DVD
DVD
Media
Result
Elapsed AvailableSelected(current)
()
Selected programme Available disc space
When the entry item is marked X, the recording does
not fit. Change the setting.
means this recording will not be executed due to
limitation of recording time, if another is executed.
RD-XS24SB_Ope_E_p025-036 8/31/05, 11:52 PM32
