GLID 100
1. Transmitter Controls
1.1 Control Identification and Location
Channel Assignment/Throttle ALT
Channel # TX Function Airplane Function
1 Spoi Spoiler Channel
2 Ail 1 Left Aileron Channel (AIL1)
3 Elev Elevator Channel
4 Rudd Rudder Channel
5 Ail 2 Right Aileron Channel (AIL 2)
6 Flap
Left Flap Channel for Dual Flaps
7 Aux 2 Right Flap Channel for Dual Flaps
8 Aux 3 Auxillary 3 Channel
Throttle ALT
This function makes the spoiler stick trim active only when the
spoiler stick is at less than 50%, which allows for fine adjustment
of the spoilers with the spoiler stick in the lower position.
Input Keys
Aileron Trim
Elevator Trim
Aileron/Elevator Stick
Antenna
Aux 2 Flapron Flap Trim Knob
(Pot #5)
Carrying Handle
LCD Display (Do Not Press)
Flap Trim Knob (Pot #6)
Aileron Dual Rate Switch
Rudder Dual Rate Switch
Mixing Switch
Power Switch
Rudder Trim
Spoiler Trim
Neck Strap Eyelet
Timer Trainer Switch
Dual Flap/Aileron
Trim Knob (Pot #7)
Elevator Dual Rate Switch
Crow Switch
Spoiler/Rudder Stick
Flap Mixing Switch
Reflex
Off
Launch
