ACRO 44
In order to use the Differential Function, flaperon or elevon
(Delta), wing mixing must be selected in the Model Set-Up
Mode and two servos must be used to operate the ailerons (one
on each). In the Function Mode, use the UP or DN key to select
Differential Aileron Mixing and access by pressing the UP and
DN keys simultaneously.
Refer to the figure below for set-up.
Note: The Differential Aileron Mixing Function will only be
shown in the Function Mode if either Flaperon or Delta wing
types have been previously selected in the System Mode.
(pg. 34 Section 3.11)
4.10 Differential Aileron Mixing (Function Mode)
Indicate present
wing type
Differential value
(NORM 0% - 100%)
Press the UP and DN keys
simultaneously to enter/exit
the Function Mode
Press the DN and Select keys
simultaneously to access the
Function Mode List Display
Press to reset
Differential Value to
factory preset
(NORM 0%)
DN
SELECT
CH CH CLEARUP
To Trim Offset
Memory function
To Snap Roll
function
DIfferential Value
Increase or
Decrease (0-100%)
4.9 Snap Roll (Function Mode), cont.
(4.9C)
Note: Display will change
when Snap Roll direction
changes are made.
Direction of Snap Roll
R-D Right Down Snap Roll
R-U Right Up Snap Roll
L-D Left Down Snap Roll
L-U Left Up Snap roll
Press the UP and DN keys
simultaneously to enter/exit
the Function Mode
Press the DN and Select keys
simultaneously to access the
Function Mode List Display
Press to
select Left
Snap
Press to
select Right
Snap
DN
SELECT
CH CH CLEARUP
Press to select
Up Snap
Press to select
Down Snap
Snap Roll Direction Change
(For Normal Display)
