HELI 58
1. Transmitter Controls
1.1 Control Identification and Location
Throttle (collective)/
Rudder Stick
Input Keys
Aileron Trim
Elevator Trim
Elevator/Aileron Stick
Antenna
Hovering Throttle Knob (Aux2)
Carrying Handle
LCD Display (Do Not Press)
Gear/Inverted Switch
Aileron Dual Rate Switch
Rudder Dual Rate Switch
Throttle Hold Switch
Power Switch
Rudder Trim
Throttle Trim
Neck Strap Eyelet
Timer/Trainer Switch
Hovering Pitch Knob
Elevator Dual Rate Switch
Flight Modes (Aux 3)
Pitch Trim Knob
Channel Assignment/Throttle ALT
Channel # TX Function Airplane Function
1 Thro Throttle Channel
2 Aile Aileron Channel
3 Elev Elevator Channel
4 Rudd Rudder Channel
5 Gear Gear Channel
6 Aux 1 Auxillary 1 Channel (Pitch)
7 Aux 2
Auxillary 2 Channel (Gyro Sensitivity)
8 Aux 3 Auxillary 3 Channel
Throttle ALT
The Throttle ALT function makes the throttle stick trim active only
when the throttle stick is at less than half throttle. This gives easy,
accurate idle adjustments without affecting the high throttle
position.
