4.2 Operating EB-DVR Playback Application
Click to run the application. Select the hard disk and then select a proper video
system according to your local video system. Click OK.
Attention:
Make sure you enter the Main Menu before use the USB function.
If you select an inappropriate video system, the video will not be normal. Please exit
the playback application and then run it again. Select the hard disk and a proper video
system according to your local video system.
When backup data via a USB cable, please ensure the jumpers settings of hard disks
to follow the table below.
Jumpers Adjustments
HDD A HDD B
Backup HDD data via a
USB Cable
WD(Master) HDD A
WD (Slave)
Hitachi (Master) HDD A
WD(Master) HDD A
Hitachi(Slave)
Hitachi(Master) HDD A
WD (Slave) HDD A
Hitachi(Slave) HDD A
Seagate (Slave) HDD A
Maxtor(Master)
Maxtor(Slave) HDD A
WD (Master) HDD A
Maxtor (Slave)
Hitachi(Master) HDD A
WD (Slave) HDD A
Hitachi(Slave) HDD A
Seagate(Master)
Maxtor (Slave) HDD A
WD (Master) HDD A
Hitachi(Master) HDD A
Seagate (Slave)
Maxtor(Master) HDD A
WD (Master) N/A HDD A
Hitachi(Master) N/A HDD A
Maxtor(Master) N/A HDD A
Maxtor(Slave) N/A HDD A
Seagate(Master) N/A HDD A
