VIDEO OUT VIDEO IN
AUDIO OUT AUDIO IN OUTPUT
INPUT
S-VIDEO
KEYBOARD
MOUSE
USB
LAN
VGA
BILL / COIN
RESET
CONTROL
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER, NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE
THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
When connecting a remote PC to JB-199 Premier unit
The connection from a remote PC to JB-199 Premier unit is illustrated below.
Note : Use the LAN 100Mbps cable included in JB-199 Premier unit.
INTERNET
HUB,
ROUTER
HOW TO CONNECT
A cross network cable can be used to directly connect a remote PC to JB-199
Premier wihout a HUB or Router. For the instruction and required settings,
please go to www.cavsusa.com/jb-199premier.htm.
32
