HOW TO OPERATE
BACKUP HARD DRIVE
It is vital to make a backup copy of the JB-199 Premier hard drive. As more and more
songs are added, even an unlikely failure of the hard drive becomes too risky to be left to
chances when measured against the damages that would be disasterous and costly.
A regular backup can make such disasters uneventful.
JB-199 Premier comes with an easy to use program that will make backup copies of
its hard drives.
Preparing a new hard drive:
- Prepare a new hard drive that is equal or larger in size (160G, 250G, etc.) to the
JB-199 Premier hard drive that you wish to backup.
- An external hard drive with USB 2.0 connector is recommended for its convenience to
connect to JB-199 Premier.
- An alternative would be an internal hard drive encased in an external case with USB 2.0
connector. Such external cases are available in most computer stores along with the hard
drives.
- The new hard drive may be formatted in any file structure or not formatted at all.
Preparing JB-199 Premier:
- For a new hard drive with USB 2.0 connector, connect to JB-199 Premier using a USB 2.0
connector in the back panel.
- For a new hard drive with IDE connector (no USB 2.0 connector),
- Switch the PIN setting of the new hard drive to SLAVE. Refer to the hard drive’s
manual for the instruction on pin settings.
- Disconnect the power cord of JB-199 Premier.
- Open the top cover of JB-199 Premier.
- Locate the IDE cable connecting the mother board and the internal hard drive of
JB-199 Premier. In the mid-section of the IDE cable, you will find an extra IDE
connector.
- Connect the new hard drive to the extra IDE connector on the IDE cable.
- Connect the new hard drive to an extra DC power cable from the Power supply.
- Place the new hard drive insulated from any open circuits or metals of JB-199 Premier.
80
