LNB(F) Configuration matrix
Appendix 1
Digital Satellite Receiver Page A1 - 1
© 2002 EchoStar International Corporation
All rights reserved
A1
APPENDIX 1
1. LNB CONFIGURATION MATRIX
In the installation menu, the different LNBs are already pre-programmed to save you a lot of
configuring routines.
2. LNBF CONFIGURATION MATRIX
In the installation menu, the different LNBFs are already pre-programmed to save you a lot of
configuring routines.
3. USER DEFINED LNB(F) MATRIX
In the User LNB setting menu, you can define your own LNB(F). You can use the list below to
note the settings.
LNB TYPE LO Frequency LO Selection 13/18V 0/22kHz
HVHV
Standard
10,000 13/18V 18 18 0 0
Enhanced
9,750 13/18V 18 18 0 0
Quattro
9,750 13V 13 13 0 0
10,750 18V 18 18 0 0
C-Band
5,150 13/18V 18 18 0 0
DBS
10,750 18V 18 18 0 0
TELECOM
11,475 18V 18 18 0 0
LNBF TYPE LO Frequency LO Selection 13/18V 0/22kHz
HVHV
Standard
10,000 13/18V 18 13 0 0
Enhanced
9,750 13/18V 18 13 0 0
Universal
9,750 0 kHz 18 13 0 0
10,600 22 kHz 18 13 22 22
Quattro
9,750 0 kHz 18 13 0 0
10,750 22 kHz 18 13 22 22
C-Band
5,150 13/18V 18 13 0 0
C-Band SS
5,150 13V 18 13 0 0
5,750 18V 18 13 0 0
User LNB(F) LO Frequency LO Selection 13/18V 0/22kHz
HVHV
User ........ 1
... ...,... ... ... ... .../... ... ... ... ... ... ... ... ... ... ...
User ........ 2
... ...,... ... ... ... .../... ... ... ... ... ... ... ... ... ... ...
