Triplex
6 Technical Specifications
General
External Power Supply
12 Volt DC. 60 Watt (5 Amp)
Connector
2.1mm barrel connector, center positive.
Power Consumption
35 Watt nominal (single disk).
Operating Temperature Range
Operating: 0 to 40°C. Storage: -20 to +60°C.
Relative Humidity Range (Non-Condensing)
Operating: 10% to 80%. Storage: 10% to 95%
Dimensions
17.5 x 14 x 1.7 Inches. 1U, 19 inch rack unit.
Weight
9 Lbs.
Connections
10/100 Ethernet Port
RJ-45 Connector.
RS232 Port 1
DB-9 Male Connector.
AUX Port
DB-9 Male Connector.
RS232 Port 2
RJ-45 Connector.
Camera Inputs
BNC connectors. Auto Terminating. Color & Mono.
Monitor-A Output (Y/C)
4-pin Mini-DIN Connector.
Monitor-B Output (Y/C)
4-pin Mini-DIN Connector.
Monitor-A Output (Composite)
BNC Connector
Monitor-B Output (Composite)
BNC Connector
RS485 Port
Two Looping RJ-45 Connectors
SCSI Port
50 pin, High Density SCSI-2 female connector.
Alarm I/O Port
Use Supplied DB-25 PCB connector.
Video
Video Signal Input
0.5 to 2.0 Volts peak-to-peak with Automatic Gain Control.
Video Signal Output
1 Volt peak-to-peak into 75-Ohm.
Input Termination
75-Ohm (Auto Terminating)
Display Memory
4 Megabytes
Resolution
Horizontal: 720 Pixels. Vertical: 484 Lines (576 for PAL).
Gray Scale
256 levels
Colors
Y:U:V 4:2:2, 16.8 Million Colors
Compression Standard
Wavelets
