RQT9058
Inserting Discs
Inserting a Video Cassette
Inserting USB memory
You can insert the USB memory directly into the USB port.
Preparation
Before inserting any USB memory to this unit, ensure that
the data stored in it has been backed up.
Opening
the front panel
Pull down.
DVD
VHS
REC
E
Inserting the USB memory
Check the orientation of the USB
connector and insert it straight in.
REC
VHS
DVD
SD CARD
REC MODE
ELECT
Removing the USB memory
Complete all USB memory-related operations and pull the
USB memory straight out.
When “uSb”(USB) is fl ashing on the unit’s display, do not
turn off the unit or remove the USB memory.
Inserting an SD Card
Notes
When “SD” is fl ashing or when copying a picture or
displaying the Album in the SD card, do not turn off the
unit or remove the SD card.
Such action may result in malfunction or loss of the
card’s contents.
Notes
When using 8 cm (3) DVD-RAM or 8 cm (3) DVD-R,
remove the disc from the cartridge.
It is not possible to record or play continuously from one
side of a double sided disc to the other. You will need to
eject the disc and turn it over.
The unit may take some time to respond to [OPEN/CLOSE].
Notes
There are few USB memory devices that cannot be connected.
Some USB devices inserted into this unit may cause this
unit to stop operating. Such USB devices cannot be used
on this unit.
Confirm that “uSb”(USB) appears on the unit’s display when
a compatible USB memory is inserted while stopped.
If a USB memory being accessed is pulled out, then the
data may be damaged.
OPEN/CLOSE
to open the tray.
– Insert a disc.
– Press [ OPEN/CLOSE] again to close the tray.
Insert label-up.
Insert a cassette.
– The unit turns on automatically.
To eject:
From the main unit:
or
From the remote control
DRIVE
SELECT
to select the VHS drive.
STOP
Press and hold for 3 or
more seconds.
EJECT
– The unit turns on automatically.
Video Cassette Information
Tab
Break off the video cassette’s tab to
prevent accidental erasure. Cover the
hole with a double layer of adhesive
tape when you want to use the video
cassette for recording again.
You can use video cassettes with the VHS and S-VHS
marks, but the unit is unable to make full use of the
characteristics of S-VHS video cassettes.
Opening
the front panel
Pull down.
DVD
VHS
REC
ODE
Inserting the card
REC
VHS
CH
SD CARD
DV IN
RESET
DRIVE SELECT
DVD
Press on the center of
the card until it clicks
into place.
Insert the card label up with
the cut-off corner on the right.
If you are using a miniSD
card/microSD card,
insert it into the card
adaptor that comes with
the card.
Insert and remove this
adaptor from the unit.
ADAPTER
Removing the card
Press on the center of the card and pull it straight out.
Media Handling
Getting Started
Basic Operations
