RQT8320
39
Linked operations with the TV (Q Link)/Child Lock/Changing the unit’s settings
Changing the unit’s settings
Refer to the control reference on page 35.
1 While stopped
Press [FUNCTIONS].
2 Press [e,r] to select “To Others” and
press [ENTER].
3 Press [e,r] to select “Setup” and
press [ENTER].
4 Press [e,r] to select the tab and
press [q].
5 Press [e,r] to select the menu and
press [ENTER].
6 Press [e,r] to select the option and
press [ENTER].
To return to the previous screen
Press [RETURN].
To exit the screen
Press [RETURN] several times.
Note
There may be differences in operation methods. If this
happens, follow the on-screen instructions for the operation.
The settings remain intact even if you switch the unit to standby.
Common procedures
Setup
Tuning
Disc
Sound
Display
Connection
Others
Remote Control
Clock
Owner ID
Initialize
DVD 1
SELECT
TAB
RETURN
Tabs Menus Options
Summary of settings
Tabs Menus Options (Underlined items are the factory presets.)
Tuning Manual (Ô page 42)
Auto-Setup Restart (Ô page 42)
Download from TV (Ô page 42)
Disc Settings for Playback
• Press [ENTER] to show the following settings.
Ratings
Set a ratings level to limit DVD-Video play.
Follow the on-screen instructions. Enter a 4-digit
password with the numbered buttons when the
password screen is shown.
• Do not forget your password.
•8 No Limit
:All DVD-Video can be played.
• 1 to 7: Prohibits play of DVD-Video with corresponding
ratings recorded on them.
• 0 Lock All:Prohibits play of all DVD-Video.
• Unlock Recorder
• Change Level
• Change Password
• Temporary Unlock
DVD-Audio Video mode Playback
Select “On” to play DVD-Video content on some
DVD-Audio.
• On: The setting returns to “Off” when you change the
disc or turn the unit off.
•Off
Soundtrack • Some discs start in a certain
language despite any changes
you make here.
• Enter a code (Ô page 50) with
the numbered buttons when you
select “Other ”. When
the selected language is not
available on the disc, the default
language is played. There are
discs where you can only switch
the language from the menu
screen (Ô page 24).
•English
• German • French • Italian
• Spanish
• Original: The original language of each disc will be
selected.
•Other
Subtitle • Automatic
:If the language selected for “Soundtrack” is not
available, subtitles of that language will
automatically appear if available on that disc.
•English •German •French •Italian
•Spanish •Other
Menus •English
• German • French • Italian
•Spanish •Other
Settings for Recording
• Press [ENTER] to show the following setting.
Recording time in EP mode
Select the maximum number of hours for
recording in EP mode (Ô page 17, Recording
modes and approximate recording times).
• EP ( 6Hours ):
You can record for 6 hours on an unused 4.7 GB disc.
• EP ( 8Hours )
:
You can record for 8 hours on an unused 4.7 GB disc.
Picture Comb Filter
Select the picture sharpness when recording.
The setting is fixed with “On” if you set “TV System”
to “NTSC” (Ô page 43).
• On: Select it to record clear picture.
•Off
: Normally, use this setting.
Still Mode
Select the type of picture shown when you pause
play (Ô page 49, Frames and fields).
• Automatic
:
• Field: Select if jittering occurs when “Automatic” is
selected. (The picture is coarser.)
• Frame: Select if small text or fine patterns cannot be
seen clearly when “Automatic” is selected. (The
picture is clearer and finer.)
DVD-V
DVD-V
DVD-V
