Specifications
Recording System
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer): DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time
Maximum 8 hours (using 4.7 GB disc)
Recordable discs
DVD-RAM: Ver. 2.0
Ver. 2.1/3x–SPEED DVD-RAM Revision 1.0
Ver. 2.2/5x–SPEED DVD-RAM Revision 2.0
DVD-R: for General Ver. 2.0
for General Ver. 2.0/4x–SPEED DVD-R Revision 1.0
for General Ver. 2.x/8x–SPEED DVD-R Revision 3.0
for General Ver. 2.x/16x–SPEED DVD-R Revision 6.0
for DL Ver. 3.0
for DL Ver. 3.x/4x–SPEED DVD-R for DL Revision 1.0
DVD-RW: Ver. 1.1
Ver. 1.x/2x–SPEED DVD-RW Revision 1.0
Ver. 1.x/4x–SPEED DVD-RW Revision 2.0
Ver. 1.x/6x–SPEED DVD-RW Revision 3.0
+R: Ver. 1.0
Ver. 1.1
Ver. 1.2
Ver. 1.3
for DL Ver. 1.0
+RW: Ver. 1.1
Ver. 1.2/4x–SPEED
Playable discs
DVD-RAM (DVD Video Recording format), DVD-R (DVD-Video
format, MP3, JPEG), DVD-R DL (Dual Layer) (DVD-Video format),
DVD-RW (DVD-Video format, DVD Video Recording format), +R, +R
DL (Double Layer), +RW, DVD-Video, DVD-Audio,
CD-Audio (CD-DA), Video CD, CD-R/RW (CD-DA, Video CD,
SVCD
1
, MP3, JPEG formatted discs), SVCD
1
1
Conforming to IEC62107.
Quick Start for Recording
1 Sec. Quick Start for Recording on DVD-RAM
2
2
From the power off state, recording on DVD-RAM starts about 1
second after first pressing the Power button and then sequentially
pressing the REC button.
Video
Video System: PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording System: MPEG2 (Hybrid VBR)
Video In (SECAM/PAL/NTSC):
AV1/AV2 (21 pin), AV3 (pin jack) 1 Vp-p 75 Ω, termination
S-Video In (SECAM/PAL/NTSC):
AV2 (21 pin), AV3 (S terminal) 1 Vp-p 75 Ω, termination
Video Out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 Ω, termination
S-Video Out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p 75 Ω, termination
RGB Out (PAL/NTSC):
AV1 (21 pin) 0.7 Vp-p (PAL) 75 Ω, termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
Y: 1.0 Vp-p 75 Ω, termination
P
B: 0.7 Vp-p 75 Ω, termination
P
R: 0.7 Vp-p 75 Ω, termination
Audio
Recording System: Dolby Digital 2ch
Audio In: AV1/AV2 (21 pin), AV3 (pin jack)
Input Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input Impedance: More than 10 kΩ
Audio Out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output Impedance: Less than 1 kΩ
Digital Audio Out:
Optical terminal (PCM, Dolby Digital, DTS, MPEG)
Television System
Tuner System: PAL-I
Channel Coverage:
UHF: CH 21–68
VHF: CH 4–13, A–J
UHF: CH 21–68
RF Converter Output: Not provided
Optical pick-up System with 1 lens, 2 integration units
(662 nm wavelength for DVDs,
780 nm wavelength for CDs)
LASER Specification
Class 1 LASER Product
Wave Length: 780 nm (CDs), 662 nm (DVDs)
Laser Power:
No hazardous radiation is emitted with the safety protection
DV Input IEEE 1394 Standard, 4 pin: 1 pc
Others
Region Code: # 2
Operating temperature: 5 ºC–40 ºC
Operating humidity range: 10 %–80 % RH (no condensation)
Power supply: AC 220 V–240 V, 50 Hz
Power consumption: Approx. 22 W
Dimensions (W×D×H): 430 mm × 316 mm × 58 mm
Mass: 3.2 kg
Note
Specifications are subject to change without notice.
Mass and dimensions are approximate.
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours/8 hours
The United Kingdom
Republic of Ireland
Language code list Enter the code with the numbered buttons.
Abkhazian: 6566 Catalan: 6765 Gujarati: 7185 Lingala: 7678 Rhaeto-Romance: Tamil: 8465
Afar: 6565 Chinese: 9072 Hausa: 7265 Lithuanian: 7684 8277 Tatar: 8484
Afrikaans: 6570 Corsican: 6779 Hebrew: 7387 Macedonian: 7775 Romanian: 8279 Telugu: 8469
Albanian: 8381 Croatian: 7282 Hindi: 7273 Malagasy: 7771 Russian: 8285 Thai: 8472
Ameharic: 6577 Czech: 6783 Hungarian: 7285 Malay: 7783 Samoan: 8377 Tibetan: 6679
Arabic: 6582 Danish: 6865 Icelandic: 7383 Malayalam: 7776 Sanskrit: 8365 Tigrinya: 8473
Armenian: 7289 Dutch: 7876 Indonesian: 7378 Maltese: 7784 Scots Gaelic: 7168 Tonga: 8479
Assamese: 6583 English: 6978 Interlingua: 7365 Maori: 7773 Serbian: 8382 Turkish: 8482
Aymara: 6589 Esperanto: 6979 Irish: 7165 Marathi: 7782
Serbo-Croatian:
8372 Turkmen: 8475
Azerbaijani: 6590 Estonian: 6984 Italian: 7384 Moldavian: 7779 Shona: 8378 Twi: 8487
Bashkir: 6665 Faroese: 7079 Japanese: 7465 Mongolian: 7778 Sindhi: 8368 Ukrainian: 8575
Basque: 6985 Fiji: 7074 Javanese: 7487 Nauru: 7865 Singhalese: 8373 Urdu: 8582
Bengali; Bangla: Finnish: 7073 Kannada: 7578 Nepali: 7869 Slovak: 8375 Uzbek: 8590
6678 French: 7082 Kashmiri: 7583 Norwegian: 7879 Slovenian: 8376 Vietnamese: 8673
Bhutani: 6890 Frisian: 7089 Kazakh: 7575 Oriya: 7982 Somali: 8379 Volapük: 8679
Bihari: 6672 Galician: 7176 Kirghiz: 7589
Pashto, Pushto:
8083 Spanish: 6983 Welsh: 6789
Breton: 6682 Georgian: 7565 Korean: 7579 Persian: 7065 Sundanese: 8385 Wolof: 8779
Bulgarian: 6671 German: 6869 Kurdish: 7585 Polish: 8076 Swahili: 8387 Xhosa: 8872
Burmese: 7789 Greek: 6976 Laotian: 7679 Portuguese: 8084 Swedish: 8386 Yiddish: 7473
Byelorussian: 6669 Greenlandic: 7576 Latin: 7665 Punjabi: 8065 Tagalog: 8476 Yoruba: 8979
Cambodian: 7577 Guarani: 7178
Latvian, Lettish:
7686 Quechua: 8185 Tajik: 8471 Zulu: 9085
