Pioneer SC-35 TV Receiver User Manual



Controlling the rest of your system (In case of SC-35)
10
99
En
Setting the backlight mode
Default setting: 1 (normal mode)
The backlight lighting pattern can be selected from
among four modes, in consideration of convenience and
battery service life.
1 Press and hold
R.SETUP
, then press “6” for three
seconds.
The LED flashes continuously.
To cancel the preset setup mode press R.SETUP.
2 Press the number button for the backlight mode
you want to set.
“1” (normal mode)
– The backlight is turned on and
off with the light button. After it lights, it turns off
automatically if no operation is performed for 10
seconds.
“2” (
frequent lighting mode
)
– The backlight turns
on when any button on the remote control is pressed.
It is turned off with the light button. After it lights, it
turns off automatically if no operation is performed
for 10 seconds.
“3” (eco mode)
– The backlight is turned on and off
with the light button. After it lights, it turns off
automatically if no operation is performed for 5
seconds.
“4” (off mode)
– The backlight does not turn on even
when the light button is pressed.
If the LED lights for one second, the setting has been
successfully completed.
If the LED flashes three, the setting has failed.
3Press
R.SETUP
to exit the setup.
Multi operation and System off
The Multi operation feature allows you to program a
series of up to 5 commands for the components in your
system.
Be sure to call up the preset codes of devices or
perform programming signals for other remote
controls before multi operation memory
programming (
page 97).
The Multi operation feature makes it easy to perform the
following operations by pressing just two buttons.
Press MULTI OPERATION and then the DVD input
function button to:
1. Switch this receiver on.
2. Switch this receiver’s input to DVD.
3. Transmit a sequence of up to five programmed
commands.
Similar to Multi operations, System off allows you to use
two buttons to stop and switch off a series of components
in your system at the same time.
1
Only one System off
operation sequence may be programmed.
Press
MULTI OPERATION
and then
SOURCE
to:
1. Transmit a sequence of up to five programmed
commands.
2. Switch off all Pioneer devices including the receiver
(except DVD recorders and VCRs).
For greater convenience, program this receiver to
perform power on/off and playback operations on non-
Pioneer devices as well.
2
(The signals for Pioneer devices
described above are not contingent on programming for
non-Pioneer devices.)
The buttons that can be programmed using Multi
operation or System off are the same buttons as those
that can be programmed for other remote controls (see
Programming signals from other remote controls on
page 97).
Note
1• Before Multi operation and System off will work correctly, you must setup the remote to work with your TV and other components (see Setting
the remote to control other components on page 97 for more on this).
• Some units may take some time to power up, in which case multiple operations may not be possible.
• Power on and off commands only work with components that have a standby mode.
2Some remote controllers for other manufacturers' devices use the same signals for switching the power on and off. In some cases, even if this
receiver is programmed to perform these commands, power to the non-Pioneer devices may not be switched on and off correctly. Program
the rec
eiver to perform t
hese commands if the non-Pioneer device uses separate signals for power on/off.
