Operation
26 CX-47HD/CX-OPAL47/CX-65HD Installation/Operation Manual
PRE
L
IMINAR
Y
Figure 4-1. Crystal Series LCD OSD Menu Structure
Setup
OSD Language
English, Français,
Español, Português or
Deutsch
OSD Timer 0, 10, 20 ... 60 sec.
PC Mode Adjust
Auto Adjust
Clock
Phase
H. Position
V. Position
Factory Reset
Overscan
(not available with PC
signals)
H. Overscan, H. Shift,
V. Overscan, V. Shift
0, 1, 2, 3 ... 10
Letterbox Mode
Letterbox or
Cinema Fill
HDMI Audio Input HDMI 1 ... HDMI 4
HDMI or
Stereo (PC Audio In)
Film Mode Off, 2:3, 2:2 or Auto
Auto Backlight Off / On
HDMI CSC HDMI 1 ... HDMI 4
Automatic, RGB or
Component
Baud Rate
115200, 19200, 9600
or 2400
SCART Off / On
Source Enable
HDMI 1 ... HDMI 4
Component 1
Component 2
RGB
Video 1
Video 2
Enable / Disable
LED Option Off / On
System Info
Model Number/
Serial Number/
Firmware Version
(read-only)
ISF Calibration
Picture Adjust
Brightness
0, 1, 2, 3 ... 100
Contrast
Color
Tint
Sharpness 0, 1, 2, 3 ... 24
ADC Phase Adj. 0, 1, 2, 3 ... 63
DNR 0, 1, 2, 3 ... 5
MPEG NR 0, 1, 2, 3 ... 63
Backlight 0, 1, 2, 3 ... 100
Color Temp.
5400, 6500, 8500 or
Custom
Gamma 2.0, 2.2 or 2.4
Save Settings
Custom, ISF Day, ISF
Night
Restore Settings
Custom, ISF Day,
ISF Night
White Balance
R/G/B Gain
128, 129 ... 256 ... 383,
384
R/G/B Offset -50, -49 ... 0 ... 49, 50
Blue Enable (Enable/Disable)
Factory Reset (No/Yes)
Splash Duration 0, 5, 10, ... 60 secs.
Source
HDMI 1
HDMI 2
HDMI 3
HDMI 4
Component 1/SCART Note: If SCART is
enabled in the Setup
menu, Component 1
and Video 1 are
disabled.
Component 2
RGB
Video 1/SCART
Video 2
Aspect Ratio
16:9
4:3
Letterbox/Cinema Fill
VirtualWide
Picture Adjust
Brightness
0, 1, 2, 3 ... 100
Contrast
Color
Tint
Sharpness 0, 1, 2, 3 ... 24
DNR 0, 1, 2, 3 ... 5
MPEG NR 0, 1, 2, 3 ... 63
Backlight 0, 1, 2, 3 ... 100
Color Temp.
5400, 6500, 8500 or
Custom
Gamma 2.0, 2.2 or 2.4
Save Settings Custom
Restore Settings
Custom, ISF Day,
ISF Night
Audio
Balance
0 (L), 1, 2 ... 10 (C) ... 18,
19, 20 (R)
Equalizer
Custom 1, Custom 2 or
Custom 3
Speaker (On/Off)
Timer
Time 12:00 AM - 11:59 PM
On Timer
Enable/Disable, Time,
Input, Volume
Off Timer Enable/Disable, Time
Sleep Timer
Off, 10, 30, 60, 120 or
180 minutes
