34 CX-47HD/CX-OPAL47/CX-65HD Installation/Operation Manual
PRE
L
IMINAR
Y
Audio To adjust the Crystal Series LCD audio settings, select Audio from the Main Menu and
press ENTER.
Balance: To adjust the left/right speaker balance, select Balance from the Audio Menu
and press ENTER. Use the left- and/or right-arrow buttons to make one channel louder
than the other.
Equalizer: The Crystal Series LCD has a five-band graphic equalizer that you can use to
boost or cut certain audio frequencies. To use it, select Equalizer from the Audio menu
and press ENTER or
.
From this menu, you can create and store audio
“modes.” A mode is a combination of volume and
equalizer settings. The viewer can then recall these
settings using the AUDIO
1, AUDIO 2 and AUDIO 3
remote control buttons.
To select and customize an audio mode –
Custom1 (AUDIO
1), Custom2 (AUDIO 2) or
Custom3 (AUDIO
3):
1. Use the or button to highlight its name. Then, press ENTER or .
2. Press or to select the Volume slider or equalizer frequency band that you want
to adjust. The five frequency bands are 100, 300, 1000, 3000 and 10,000 Hertz (Hz).
3. Use the or button to adjust according to taste.
4. Repeat Steps 2 and 3 for the other settings, as desired.
5. To edit another audio mode, press ENTER to store your settings and repeat Steps 1
through 4.
6. Press MENU or EXIT when you have finished configuring audio modes.
Speaker: To disable the speakers, select Speaker from the Audio menu, set it to Off and
press ENTER. The effect is similar to using the MUTE button, except that the Crystal
Series LCD “remembers” this setting if you turn off the display, then turn it back on.
Timer To set the Crystal Series LCD’s internal clock or configure the on/off timers, select Timer
from the Main Menu and press ENTER.
Time: To set the Crystal Series LCD internal clock, select Time from the Timer menu and
press ENTER. Then, use the left- or right-arrow button to select the hour of the day,
AM/PM or the minute of the hour to set. Then, use the up- or down-arrow buttons to set
that component of the time.
When finished, press MENU or EXIT.
On Timer: Use the On Timer to turn the Crystal Series LCD on at a specific time of day.
You can also specify a source input and volume level.
Off Timer: Use the Off Timer to turn the Crystal Series LCD off at a specific time of day.
Audio
Balance
Equalizer
Speaker
➤
PIP POSITION SIZE SWAP
PIP SRC AUDIO 1 AUDIO 2 AUDIO 3
Timer
Time
On Timer
Off Timer
Sleep Timer
➤
