ISF Calibration Use the ISF Calibration menu to perform advanced picture quality adjustments. This
menu should be used by ISF-certified technicians only.
Picture Adjust: The controls in this menu are identical to those in the main Picture Adjust
menu, but are accessible only by entering the ISF Calibration menu passcode. This makes
it possible to restore the picture quality settings to what they were when the Crystal Series
LCD was installed, simply by recalling the “ISF Night” or “ISF Day” preset.
•Brightness: Refer to Brightness on page 29.
• Contrast: Refer to Contrast on page 30.
• Color: Refer to Color Saturation on page 31.
•Tint: Refer to Tint on page 31.
• Sharpness: Refer to Sharpness on page 32.
• ADC Phase Adj.: This control works similarly to the Phase adjustment for RGB signals
(refer to
Phase on page 35). Use it to improve the apparent sharpness of 720p and
lower-resolution Component, S-Video or Composite sources. For best results, adjust
ADC Phase while displaying a “Sharpness” pattern (
Figure 4-5).
• DNR: Refer to DNR on page 32.
• MPEG NR: Refer to MPEG NR on page 32.
• Backlight: Refer to Backlight on page 32.
• Color Temp.: To choose a color temperature setting, select Color Temp. from the
Picture Adjust menu and press ENTER. (Color temperature defines the “color of gray.”)
The choices are 5400K, 6500K, 8500K and Custom. The default setting, 6500K, is
appropriate for most situations. Higher settings produce a “bluer” picture; lower ones
impart a reddish hue to the image.
Each color temperature setting has six (6) “white balance” parameters associated with
it (two each for red, green and blue). (The White Balance settings for the 5400K, 6500K
and 8500K color temperatures are factory-set and cannot be changed.)
• Gamma: Refer to Gamma on page 33.
• Save Settings: For each input and supported resolution, the Crystal Series LCD lets
you save image quality settings as presets that you can recall at a later time. You can
create up to three presets – designated “Custom,” “ISF Day” and “ISF Night” – per
input and resolution.
You should save changes to any of the following settings to a preset; otherwise they
will be lost when a new input source or resolution is selected:
•Brightness
•Contrast
• Color saturation
ISF Calibration
Picture Adjust
White Balance
Blue Enable
Factory Reset
Splash Duration
➤
You must enter a passcode to access the ISF Calibration menu.
To create a “Custom” color temperature, select Custom from the
Color Temp. menu and press ENTER. Then, press ENTER a
second time to go directly to the
White Balance menu. (This shortcut
is available only from the ISF Calibration menu.)
Note
Tip
