Installation
Runco CinemaWall SP-42/-50/-60 Owner’s Operating Manual 17
PRE
L
IMINAR
Y
• As it lies flat with the screen face
down. Place the protective sheet,
which was wrapped around the
plasma monitor when it was
packaged, between the screen and
your work surface to avoid
scratching or otherwise damaging
the screen surface.
Ambient LightIn general, minimize or eliminate light sources directed at the display. Contrast ratio in your
images will be noticeably reduced if light directly strikes the display, such as when a shaft
of light from a window or floodlight falls on the image. Images may then appear washed
out and less vibrant.
VentilationIf you are mounting the CinemaWall in an enclosure, leave at least 2 inches (50 mm) of
space on all sides between it and surrounding objects, as shown in
Figure 3-2. This allows
heat to disperse, maintaining the proper operating temperature.
Figure 3-2. Ventilation Requirements for Enclosure Mounting
50
mm
(2")
50
mm
(2") 50
mm
(2")
Wall
Wall
50
mm
(2")
50
mm
(2")
