Operation
Runco CinemaWall SP-42/-50/-60 Owner’s Operating Manual 39
PRE
L
IMINAR
Y
V Size (Installer Adjust mode): Use the up- or down-arrow buttons ( , ) to highlight
V Size. Then, press SET and use the right-arrow button ( ) to increase the height; use
the left-arrow button ( ) to decrease it.
H Size (Installer Adjust mode): Use the up- or down-arrow buttons ( , ) to highlight
H Size. Then, press SET and use the right-arrow button ( ) to increase the width; use
the left-arrow button ( ) to decrease it.
Image Reset: To reset all screen settings for the current input to the default, Installer
Adjust mode values, select Image Reset from the Screen menu. Then, press
to
highlight YES and press SET.
Set-UpColor Temperature: To adjust the color temperature, select Color Temperature from
the Set-Up menu. (Color temperature defines the “color of gray.”) Use the left- and/or
right-arrow buttons to select LOW, MID-LOW, MIDDLE, MID-HIGH or HIGH. The default
setting, MIDDLE, is appropriate for most situations. Higher settings produce a “bluer”
picture; lower ones cause the image to appear more red.
Auto Off: When using the CinemaWall with a computer, set Auto Off to ON to have the
CinemaWall go into standby mode when no source signal is present on the current input.
(A warning message appears on-screen for approximately eight seconds before this
occurs.) To return to normal operating mode from the Auto Off standby mode, select the
input with the remote control or operate your computer.
When Auto Off is disabled (OFF), the CinemaWall remains in normal operating mode,
regardless of the presence or absence of an input sync signal.
The STANDBY/ON indicator at the front of the CinemaWall indicates the status of the
power management function, as described in
Table 4-2.
Video NR: To apply Digital Noise Reduction (DNR) to the input signal, select Video NR
from the Set-Up menu. Noise reduction is useful for improving the signal-to-noise ratio of
video signals.
INPUT 2
CINEMAWALL
SCREEN SET-UP OPTION
COLOR TEMP. : MIDDLE
VIDEO NR
: MIDDLE
AUTO OFF
: OFF
MPEG FILTER
: LOW
CHROMA EE
: ON
FILM MODE : OFF
COLOR SPACE : RGB
DVI SET UP
SIGNAL : 720p
SETSET
EXIT
MENU
INPUT 1
INSTALLER ADJUST
SCREEN SET-UP OPTION
BRT. ENHANCE : OFF
SUB VOLUME
: +20
SETSET
EXIT
MENU
1. If the computer is turned off or not properly connected to the
CinemaWall, the system is set to the off state.
2. For instructions on using the computer's power management
features, refer to the instructions for your computer.
Table 4-2. Power Management Indications
Power
management
mode
STANDBY/
ON
Indicator
Power
management
operating status
Description
Turning the
picture back on
ON Solid
green
Not activated. Horizontal and ver-
tical synchronizing
signals are present
from the com
-
puter.
Picture already on.
OFF Flashing
green
Activated. Horizontal and/or
vertical synchroniz
-
ing signals are not
present from the
computer.
Press a key on the
keyboard or move
the mouse. The
picture reappears.
Note
