Serial Communications
Runco CinemaWall SP-42/-50/-60 Owner’s Operating Manual 55
PRE
L
IMINAR
Y
SZMS06 53 5A 4D 53 30 36 – – Sets the aspect ratio to 14:9.
SZMS09 53 5A 4D 53 30 39 – – Sets the aspect ratio to UNDERSCAN.
SZMS10 53 5A 4D 53 31 30 – – Sets the aspect ratio to VIRTUAL
CINEMA.
Video
PMTS00 50 4D 54 53 30 30 – – Turns video muting off. (Note 2)
PMTS01 50 4D 54 53 30 31 – – Turns video muting on. (Note 2)
STLS00 53 54 4C 53 30 30 – – Turns the STILL setting to OFF.
(Note 2)
STLS01 53 54 4C 53 30 31 – – Turns the STILL setting to ON. (Note 2)
Audio
AMTS00 41 4D 54 53 30 30 – – Turns audio mute OFF. (Note 2)
AMTS01 41 4D 54 53 30 31 – – Turns audio mute ON. (Note 2)
AUSS01 41 55 53 53 30 31 – – Sets audio source to main.
AUSS02 41 55 53 53 30 32 – – Sets audio source to sub.
VOL 56 4F 4C 000 042 Adjusts the audio volume.
Picture-in-Picture (PIP)
MSCS00 4D 53 43 53 30 30 – – Turns 2-screen display operation OFF.
MSSS01 4D 53 53 53 30 31 – – Sets PIP sub-screen size to 1 (small-
est).
MSSS02 4D 53 53 53 30 32 – – Sets PIP sub-screen size to 2.
MSSS03 4D 53 53 53 30 33 – – Sets PIP sub-screen size to 3.
MSSS04 4D 53 53 53 30 34 – – Sets PIP sub-screen size to 4 (largest).
MSTS01 4D 53 54 53 30 31 – – Sets 2-screen operation to 2 SCREEN
(side-by-side; main screen on left).
Table 6-1. Serial Commands (continued)
Command Value Range
Description
ASCII HEX Minimum Maximum
Notes:
1. When making input-specific adjustments such as to image quality, screen position/size or audio
sub-volume, select the input you wish to affect before making such adjustments.
2. These settings are not stored in memory.
