Runco CinemaWall SP-42/-50/-60 Owner’s Operating Manual 61
PRE
L
IMINAR
Y
GRAS24 47 52 41 53 32 34 – – Sets the GAMMA to 2.4.
RHI 52 48 49 000 255 Adjusts red gain (highlight).
RLW 52 4C 57 000 255 Adjusts red offset (lowlight).
SHP 53 48 50 000 015 Adjusts the SHARPNESS.
STD 53 54 44 – – Executes FACTORY and WHITE BAL.
RESET commands.
TNT 54 4E 54 000 060 Adjusts the TINT.
SCREEN Menu Commands (Installer Adjust Mode)
CFR 43 46 52 000 255 Adjusts clock (PLL) frequency.
CPH 43 50 48 000 031 Adjusts PLL phase.
FRP 46 52 50 – – Executes IMAGE RESET.
HPS 48 50 53 064 191 Adjusts Horizontal position .
HSI 48 49 53 000 064 Adjusts Horizontal size (width).
VPS 56 50 53 064 191 Adjusts the Vertical position.
VSI 56 53 49 000 064 Adjusts Vertical size (height).
SET-UP Menu Commands (Installer Adjust Mode)
SVL 53 56 4C 000 020 Adjusts the sub-volume.
OPTION Menu Commands (Installer Adjust Mode)
BPIS01 42 50 49 53 30 31 – – Sets BANNER PIP input to INPUT1.
BPIS02 42 50 49 53 30 32 – – Sets BANNER PIP input to INPUT2.
BPPS00 42 50 50 53 30 30 – – Sets BANNER PIP to OFF.
BPPS01 42 50 50 53 30 31 – – Sets BANNER PIP position to TOP.
BPPS02 42 50 50 53 30 32 – – Sets BANNER PIP position to
MID-HIGH.
BPPS03 42 50 50 53 30 33 – – Sets BANNER PIP position to
MID-LOW.
BPPS04 42 50 50 53 30 34 – – Sets BANNER PIP position to BOT-
TOM.
BSL 42 53 4C 000 255 Adjusts BLUE sidebar level.
CLMS00 43 4C 4D 53 30 30 – – Sets the ISF SETTING to NORMAL.
Table 6-1. Serial Commands (continued)
Command Value Range
Description
ASCII HEX Minimum Maximum
Notes:
1. When making input-specific adjustments such as to image quality, screen position/size or audio
sub-volume, select the input you wish to affect before making such adjustments.
2. These settings are not stored in memory.
