Runco CinemaWall SP-42/-50/-60 Owner’s Operating Manual 65
PRE
L
IMINAR
Y
7.1
CinemaWall
Specifications
Table 7-1 lists the CinemaWall specifications.
7. Specifications
Table 7-1. CinemaWall Specifications
Native Resolution: Model SP-42: 1024 x 768
Model SP-50: 1365 x 768
Model SP-60: 1365 x 768
Screen Size (diagonal): Model SP-42: 42 in.
Model SP-50: 50 in.
Model SP-60: 60 in.
Active Screen Area: Model SP-42: 36.28 x 20.29 in. (921.6 x 515.3 mm)
Model SP-50: 43.45 x 24.50 in. (1103.6 x 622.3 mm)
Model SP-60: 51.93 x 29.21 in. (1319.0 x 741.9 mm)
Screen Aspect Ratio: 16:9
Available Aspect Ratios: Standard 4:3, Letterbox, 16:9 Anamorphic, VirtualWide™,
Virtual Cinema™, 14:9, Pix-by-Pix (no re-sizing)
DTV Compatibility: 480i/p, 525i/p, 540p, 625i/p, 720p, 1035i, 1080i; 50/60 Hz
ISF Settings: Yes
Data/Graphics Compatibility: Refer to Table 7-2
Inputs: (1) RGB/Component (15-pin D-sub); compatible with
Microsoft “Plug & Play” (VESA DDC 1/2B)
(1) DVI with HDCP; compatible with Microsoft “Plug & Play”
(VESA DDC 2B)
(1) Composite Video or S-Video (switch-selectable)
(1) HD Component
(1) DVI Video with HDCP
(5) Audio (stereo mini-jack); 500 mV RMS / > 10 kΩ
(1) RS-232 (9-pin D-sub female)
Outputs: (1) RGB (15-pin D-sub)
(1) Speaker Terminals (stereo pair)
(1) Audio (stereo mini-jack); 500 mV RMS / < 5 kΩ
Audio System: Internal amplifier
Output Power =
8W RMS x 2 at 6Ω (Model SP-42)
9W RMS x 2 at 6Ω (Models SP-50 and SP-60)
Power Requirements: 100 to 240 VAC, 50/60Hz
Power Consumption: Model SP-42: 360 watts (1.5 watts in standby), maximum
Model SP-50: 375 watts (1.5 watts in standby), maximum
Model SP-60: TBD
Operating Environment: 40ºF to 95ºF (5ºC to 35ºC);
20% to 80% humidity (non-condensing)
Altitude = up to 6,000 feet (1,828m)
