Page 4-13CHAPTER 4 — PROGRAMMABLE FUNCTION STRINGS
If the printer is capable of printing any font at any pitch (CPI), then this
PFS should set the pitch for the current font. If a specific font is needed to
achieve 15 CPI, then this PFS should be defined to select that font.
If the RES CPI= option (under FMTINFO: for the output port) is set to
PRE-FONT, then this PFS will be sent before the GFID for the font is sent.
If the RES CPI= option is set to POSTFONT then this PFS will be sent
after the GFID for the font is sent.
P 16CPI
Print 16 characters per inch in portrait orientation. This PFS is sent to the
printer when the 5250 OPTIMAs page orientation algorithm has selected
a portrait orientation, and when the System has requested a font with a
pitch of greater than 15 but less than or equal to 16 CPI (using either an
SCS Set Character Density command or an SCS Set FID through GFID
command).
If the printer is capable of printing any font at any pitch (CPI), then this
PFS should set the pitch for the current font. If a specific font is needed to
achieve 16 CPI, then this PFS should be defined to select that font.
If the RES CPI= option (under FMTINFO: for the output port) is set to
PRE-FONT, then this PFS will be sent before the GFID for the font is sent.
If the RES CPI= option is set to POSTFONT then this PFS will be sent
after the GFID for the font is sent.
P 17CPI
Print 17 characters per inch in portrait orientation. This PFS is sent to the
printer when the 5250 OPTIMAs page orientation algorithm has selected
a portrait orientation, and when the System has requested a font with a
pitch of greater than 16 CPI (using either an SCS Set Character Density
command or an SCS Set FID through GFID command).
If the printer is capable of printing any font at any pitch (CPI), then this
PFS should set the pitch for the current font. If a specific font is needed to
achieve 17 CPI, then this PFS should be defined to select that font.
If the RES CPI= option (under FMTINFO: for the output port) is set to
PRE-FONT, then this PFS will be sent before the GFID for the font is sent.
If the RES CPI= option is set to POSTFONT then this PFS will be sent
after the GFID for the font is sent.
