Appendix A
System Specifications
A.1 Antenna Specifications
Physical Characteristics
Antenna Unit 53 cm (21") h x 49 cm (19.2") d;
13.6 kg (30 lbs)
Operating temperature –25° to +55° C (–13° to +130° F)
Storage temperature –40° to +85° C (–40° to +185° F)
Humidity to 100% non-condensing
Input Power
Input 11–16v DC @ 3.5 amps nominal
(4.5 amps peak)
Antenna System Performance
Minimum EIRP 50-51 dB
Elevation range 20° - 85°
Azimuth range 720°
Pitch/roll range ±15°
Pitch/roll rate 45°/second
Turn rate 45°/second
Yaw ±90° in 10 seconds
Tracking rate 30° per second
Position repeatability 0.1°
Surge/sway/heave ±0.2 G
Shock 20 G, 11 msec
Vibration 0.9 G rms over 5-33 Hz
A-1
System Specifications
54-0150 Rev. D
Table A-1
TracVision 4 Antenna
Physical Specifications
Table A-2
TracVision 4 Power Specifications
Table A-3
TracVision 4 Performance
Specifications
