INTRODUCTION
PREPARATION
WATCHING TV
USING FUNCTIONS OPERATING DVD
CONNECTING DEVICES
INFORMATION USEFUL TIPS
salut!
hola!
hi!
TV Screen Display Mode
5 types of display modes can be selected when the broadcasting station is sending 16:9 or 4:3 video signal. And 3 types of display
modes can be selected for PC input signal.
Press SCREEN MODE
repeatedly to switch the TV aspect ratio.
For 16:9 video signal
Normal displays a 16:9 picture at its original size.
4:3 displays a 16:9 picture at a 4:3 size; the picture is
shortened horizontally. Sidebars appear on both edges
of the screen.
Movie expand displays a 16:9 picture that is
vertically stretched to fi ll the screen. This only crops
out the top of the picture.
Zoom displays a 16:9 picture at its maximum size
without changing its horizontal and vertical ratio.
Wide displays a horizontally stretched picture. This
crops out the left and right sides of the picture.
Normal
Wide
4:3 Movie expand
Zoom
For 4:3 video signal
Normal displays a 4:3 picture at its original size.
Sidebars appear on both edges of the screen.
16:9 displays a 4:3 picture at a 16:9 size; the picture is
stretched horizontally to fi ll the screen.
Movie expand displays a 4:3 picture at a 16:9 size;
the picture is stretched more vertically at the top of
the screen. This crops out the top of the picture.
Zoom displays a 4:3 picture at a 16:9 size; at its
maximum size that is more vertically stretched to fi ll
the screen. This crops out the top and bottom of the
picture.
Wide displays the picture with its center at the
original size and the edges stretched horizontally to fi ll
the screen.
Normal
Wide
16:9 Movie expand
Zoom
For PC input signal
Normal displays a proportionately stretched picture.
Sidebars appear on both edges of the screen.
Full displays a picture that is stretched out of
proportion horizontally to fi ll the screen.
Dot By Dot displays a picture in its original size.
Normal Dot By DotFull
Sound Functions
describe how to change the audio or the audio language as well as the volume.
Volume Adjustment
Silence Mode
Press MUTE to turn off the sound temporarily.
Mute
will be is displayed for a few seconds.
• Press MUTE again or VOL. ▲/▼ to recover the original
volume.
Use VOL.
▲/▼ to adjust the volume.
Volume 30
will be displayed for a few seconds when adjusting the volume.
Switching Audio Mode
AT SC
Press AUDIO repeatedly to cycle through the available audio
languages.
• Available languages differ depending on the broadcast.
• [Other] is displayed when the audio language cannot be
acquired, or the acquired languages are other than English,
Spanish or French.
English 1/3
11−1
NTSC
Press AUDIO to display the currently selected audio mode.
While receiving an MTS broadcast, press repeatedly to cycle
through the available audio channel.
SAP / STEREO
11
e.g.) When all audio are available
SAP / STEREO SAP / MONO SAP / STEREO
STEREO : Outputs stereo-audio
SAP : Outputs second audio program
MONO : Outputs mono-audio
