• When you have not set up your PIN code,
enter 0, 0, 0, 0.
• When the PIN code is correct, [Child Lock] menu is
displayed.
See the following description for setting each item.
Sound
Channel
Features
Language
DVD
Child Lock
Channel Lock
US Movie Ratings Lock
US TV Ratings Lock
Canadian English Rating
Canadian French Rating
Region Ratings Lock
Clear Region Ratings Lock
Change PIN
A
B
C
D
Note
• When you select a rating and set it to [Block], the higher ratings
will be blocked automatically. The lower ratings will be available for
viewing.
• When you set the highest rating to [View], all ratings turn to
[View] automatically.
• To block any inappropriate programs, set your limits in [US Movie
Ratings Lock], [US TV Ratings Lock] and [Region Ratings Lock].
• The child lock setting will be retained after a power failure or after
the power is removed for longer than 10 seconds (except the PIN
code reverts to 0000). [Child Lock]
➠
p.21
• If the rating is blocked, will appear.
• [Region Ratings Lock] will be available when the unit receives a
digital broadcast using the new rating system.
• For the United States, the unit may download the Region Ratings
Lock Table, if required.
• The Canadian rating systems on this unit are based on CEA-766-A
and CRTC policy.
A. Channel LockA. Channel Lock
Particular channels or external input modes can be invisible in
this function.
1 Use ▲/▼ to select [Channel Lock], then press ENTER.
2 Use ▲/▼ to select the desired rating, then press ENTER
repeatedly to switch between [View] and [Block].
Sound
Channel
Features
Language
DVD
Channel Lock
Video
Component
HDMI 1
HDMI 2
PC
DVD
40-1 DTV
Select
ENTER
View / Block Back
B. Setting US Movie ratingsB. Setting US Movie ratings
US Movie ratings lock is the rating system created by MPAA.
1 Use ▲/▼ to select [US Movie Ratings Lock], then press
ENTER.
2 Use ▲/▼ to select the desired rating, then press ENTER
repeatedly to switch between [View] and [Block].
Sound
Channel
Features
Language
DVD
US Movie Ratings Lock
X
NC-17
R
PG-13
PG
G
NR
Select
ENTER
View / Block Back
Rating Category
X Mature audience only
NC-17 No one under 17 admitted
R
Restricted; under 17 requires accompanying
parent or adult guardian
PG-13 Unsuitable for children under 13
PG Parental guidance suggested
G General audience
NR No rating
C. Setting TV ratingsC. Setting TV ratings
1 Use ▲/▼ to select [US TV Ratings Lock], then press
ENTER.
2 Use ▲/▼ / ◄/► to select the desired rating, then press
ENTER repeatedly to switch between [View] and [Block].
Sound
Channel
Features
Language
DVD
US TV Ratings Lock
FV V S L D
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
Select
ENTER
View / Block Back
Rating Category
TV-MA Mature audience only higher
TV-14 Unsuitable for children under 14
TV-PG Parental guidance suggested
TV-G General audience
TV-Y7
Appropriate for all children 7 and
older
TV-Y Appropriate for all children lower
To set the sub ratings
As for TV-MA, TV-14, TV-PG, or TV-Y7, you can further set the
sub ratings to block specifi c elements of programming. To set
the sub ratings, follow the step below.
Use ▲/▼ / ◄/► to select the desired rating, then press
ENTER repeatedly to switch between [View] and [Block].
