Supplied Accessories
Owner’s Manual Quick Start Guide
Installation
EN
Installation
FR
Instalación
ES
If you have any questions, please visit our website at
www.
sylvaniaconsumerelectronics .com
Quick
Start
Registration card
Remote Control
(NF033UD)
Batteries
(AA, 1.5V x 2)
AA
AA
TV base and 3 screws
(M4 x 12 )
Note
• If you lose the screws, please purchase M4×12 Phillips head screws
at your local store.
• If you need to replace these accessories, please refer to the part
No. with the illustrations and call our toll free customer support
line found on the cover of this manual.
When using a universal remote control to operate this unit.
• Make sure the component code on your universal remote control
is set to our brand. Refer to the manual accompanying your
remote control for more details.
• We do not guarantee 100% interoperability with all universal
remote controls.
Mounting the Unit on Your Furniture
Screw this unit on your furniture tightly using wood screws
(not supplied) in the 2 holes at the back of the base as shown.
• Recommended screw dimension : 0.201 x 0.788 inches (5.1 x 20 mm)
screw holesscrew holes
rear of this unitrear of this unit
Note
• When you remove this unit make sure to unscrew the wood
screws from your Wood Stand, Furniture and other wood item.
Tilt Stand
You can adjust the stand to
change the angle of the unit
(-2.5° to 10°).
10°
-2.5°
Attaching the Base
You must attach the base to the unit to have it as a table top
unit. Be sure the front and rear of the base match the proper
direction.
1 Spread a thick and soft cloth over a table as shown at step 2.
Place the main unit face down onto it. Make sure not to
damage the screen.
2 Insert 2 hooks under the
bottom of the main unit into
base holes. (shown by arrow
➀
), then move the base in
the direction as shown by
arrow
➁
until it stops and the screw holes are aligned.
Make sure not to put the AC power cord between the
base and the unit.
3 Drive Phillips head screws
into the 3 threaded holes at
the bottom of the base until
they are tight.
To remove the base from this unit
• Unscrew the Phillips head screws in step 3.
After the screws are removed, move the base in the opposite
direction as shown by arrow in step 2, then pull the base up toward
the rear of the unit. Be careful not to drop the base when you
remove it.
Note
• When attaching the base, ensure that all screws are tightly fastened.
If the base is not properly attached, it could cause the unit to fall,
resulting in injuries as well as damage to the unit.
• Make sure to use a table which can support the weight of this unit
and is larger than this unit.
• Make sure the table is in a stable location.
• When attaching the base, ensure that FRONT
↑
written on the
base is upward. If it’s not upward, the 2 hooks don’t fi t in the base.
Installing the Batteries
Install the batteries (AA, 1.5V x 2) matching the polarity
indicated inside battery compartment of the remote control.
Battery Precautions:
• Be sure to follow the correct polarity as indicated in the battery
compartment. Reversed batteries may cause damage to the
device.
• Do not mix different types of batteries together (e.g. Alkaline and
Carbon-Zinc, or rechargeable batteries like ni-cad, ni-mh, etc) or
old batteries with fresh ones.
• If the device is not to be used for a long period of time, remove
the batteries to prevent damage or injury from possible battery
leakage.
• Do not try to recharge batteries; they can overheat and rupture.
➁
➀
