Panasonic DMR-E100H DVD Recorder User Manual



67
RQT6986
Reference
Specifications
Recording system:
DVD video recording standards (DVD-RAM),
DVD video standards (DVD-R)
Optical pick-up: System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 790 nm
wavelength for CDs)
Recordable discs: 12 cm (5
q
) 4.7 GB DVD-RAM discs
12 cm (5
q
) 9.4 GB DVD-RAM discs
8 cm (3
q
) 2.8 GB DVD-RAM discs
12 cm (5
q
) 4.7 GB DVD-R discs
8 cm (3
q
) 1.4 GB DVD-R discs
(for General Ver. 2.0)
12 cm (5
q
) 4.7 GB DVD-R discs
(for General Ver. 2.0/4k–SPEED DVD-R
Revision 1.0)
Recording time: Max. 6 hours (using 4.7 GB disc)
XP: 60 minutes
SP: 120 minutes
LP: 240 minutes
EP: 360 minutes
Max. 160 hours (using Built-in HDD: HDD
capacity 120 GB)
XP: 26 hours
SP: 52 hours
LP: 104 hours
EP: 160 hours
(Continuous Recording time is 6 hours max.)
Discs played: 12 cm (5
q
) 4.7 GB DVD-RAM discs
12 cm (5
q
) 9.4 GB DVD-RAM discs
8 cm (3
q
) 2.8 GB DVD-RAM discs
12 cm (5
q
) 4.7 GB DVD-R discs
8 cm (3
q
) 1.4 GB DVD-R discs
(for General Ver. 2.0)
12 cm (5
q
) 4.7 GB DVD-R discs
(for General Ver. 2.0/4k–SPEED DVD-R
Revision 1.0)
DVD-VIDEO discs
CD-Audio discs (CD-DA)
Video CD discs
DVD-Audio discs
CD-R/CD-RW discs
(CD-DA, Video CD, MP3 formatted discs)
Drive unit: High Speed Drive
(DVD-R 4k recording speed compatible)
Card unit:
1 Still pictures (JPEG, TIFF)
Card slot: SD Memory Card/PC Card Type II
Compatible media: SD Memory Card, Multi Media Card, A PC
Card conforming to PC Card Standards,
ATA Flash PC card, PC Card adaptor (SD
Memory Card, Multi Media Card, Compact
Flash, Smart Media, Memory Stick, xD pic-
ture card, Microdrive), Mobile hard disk
Format: FAT12 or FAT16
Image format: JPEG conforming to DCF (Design rule for
Camera File system)
(sub sampling; 4:2:2 or 4:2:0)
TIFF (Uncompressed RGB chunky)
DPOF Compatible
Number of pixels: 320 a 240 to 6144 a 4096
Thawing time: Approx. 7 s (2 M pixels, JPEG)
2 SD Video MPEG4
Card slot: SD Memory Card/PC Card Type II
Compatible media:
SD Memory Card, Multi Media Card (Super
fine cannot be used), Mobile hard disk (read
only)
Video recording system:
MPEG 4 conforming
Number of pixels: Super fine/Fine 320 a 240 (QVGA)/Normal/
Economy 176 a 144 (QCIF)
Recording rate (Max):
Super fine 1050 kbps/Fine 430 kbps/
Normal 300 kbps/Economy 100 kbps
(Including audio recording rate of 32 kbps)
Audio recording system:
G.726 conforming
File format: SD VIDEO specification compliant (ASF)
3 SD Video MPEG2
§
Card slot: SD Memory Card/PC Card Type II
Compatible media: SD Memory Card, Multi Media Card, Mobile
hard disk (read only)
File format: SD VIDEO specification compliant
Video system
TV system: NTSC system, 525 lines, 60 fields
Recording system: MPEG2 (Hybrid VBR)/MPEG4
Input: LINE (pin jack)a3, 1.0 Vp-p; 75
S connectora3 Y: 1.0 Vp-p; 75
C: 0.286 Vp-p; 75
Output: LINE (pin jack)a2,1.0 Vp-p; 75
S connectora2 Y: 1.0 Vp-p; 75
C: 0.286 Vp-p; 75
Component video output (480P/480i):
Y: 1.0 Vp-p; 75
P
B: 0.7 Vp-p; 75
P
R: 0.7 Vp-p; 75
Antenna reception input:
TV Channel: 2ch–69ch, 75
CATV Channel: 1ch–125ch, 75
Audio system
Recording system: Dolby Digital (XP/SP/LP/EP)
LINEAR PCM (XP mode only)
Input: LINE (pin jack)a3
Reference input: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Input impedance: 47 k
Output: LINE (pin jack)a2
Reference output: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Output impedance: 1 k
(Load impedance: 10 k)
Number of channels: Recording: 2 channels
Playback: 2 channels
Other input/output connectors:
Digital audio optical output connector
(PCM, Dolby Digital, DTS)
Operating temperature range:
5 oC–40 oC (41 oF–104 oF)
Operating humidity range:
10 %–80 % RH (no condensation)
Clock unit: Quartz-controlled 12-hour digital display
LASER Specification
Class I LASER Product
Wave Length: 779–791 nm 653–662 nm
Laser Power: No hazardous radiation is emitted with
the safety protection
DV input: IEEE 1394 Standard, 4 pin
Power supply: AC 120 V, 60 Hz
Power consumption: 42 W
Dimensions: Approx. 430 (W)k79 (H)k296 (D) mm
[Approx.16
15
/
16
q
(W)
k
3
1
/
8
q
(H)
k
11
11
/
16
q
(D)]
(excluding protrusions)
Mass: Approx. 5.5 kg (12.13 lbs)
[Note]
Specifications are subject to change without notice.
Mass and dimensions are approximate.
§
Play is possible after converting the video recoding standard and
transferring to the HDD/DVD-RAM.
Power consumption in standby mode: approx. 3.5 W
