Panasonic DMR-ES35V DVD Recorder User Manual



17
RQTV0136
Recording television programmes
[1] Press [<, OPEN/CLOSE] on the main unit to open
the tray.
You can insert a cartridge or non-cartridge disc.
[2] Press [<, OPEN/CLOSE] on the main unit to close
the tray.
If you insert a DVD-RAM with the write-protect tab set to “PROTECT”
(l 55), play starts automatically.
Notes
A double-sided disc should be loaded with the side you want to record/
play facing down.
It is not possible to record continuously from one side of a double-sided
disc to the other. You will need to eject the disc and turn it over.
When using 8 cm DVD-RAM or 8 cm DVD-R, remove the disc from the
cartridge.
The surface on which you can
see a roll of tape should face
up.
Insert a video cassette.
The unit is automatically turned
on.
Play starts automatically if you
insert a video cassette without
the accidental erasure
prevention tab.
To eject a video cassette
You can eject a video cassette even when the unit is in standby mode. It
switches back to standby once it ejects the video cassette.
For main unit
Press [<, EJECT] on the main unit.
For remote control
Press [DRIVE SELECT] to select the VHS and then press and hold
[, STOP] for about 3 seconds or more.
[+RW]
The created title menu is deleted when recording on the disc.
Create the title menu again by using “Create Top Menu” in DVD
Management. (l 55)
[VHS]
Video cassette care
Poor quality or damaged video cassettes can cause the heads to
become dirty and malfunction. Store your video cassettes carefully and
discard them when they become dirty or damaged.
Never use video cassettes on which juice has been spilled or those that
are extremely damaged since this will not only cause the heads to
become dirty, but will also make the unit malfunction.
Video cassette maintenance
Cleaning the video heads
Dirt on the video heads can cause poor recording and play.
If the picture does not improve, use an optional head-cleaning cassette.
If the problem persists seek advice from a qualified service personnel.
[DVD]
Finalize (l 56) the disc to make it playable on other equipment or set the
protection (l 55) so that you do not accidentally erase the contents.
[VHS]
Break off the video cassette’s tab to
prevent accidental erasure. Cover the
hole with a double layer of adhesive tape
when you want to use the video cassette
for recording again.
You can use video cassettes with the
VHS and S-VHS marks, but the unit is unable to make full use of the
characteristics of S-VHS video cassettes.
Inserting a disc
Inserting a video cassette
(2)
(3)
(1)
Non-cartridge disc Cartridge disc
(1) Insert label-up.
(2) Insert fully so it clicks into place.
(3) Insert label-up with the arrow facing in.
Before recording
After recording
Tab
STEP 3 Set up to match your TV and remote control/Recording television programmes
Recording
