2. Archive video of AVI Clips into SD Card
Please take the following steps to archive a critical video in a SD card.
(1) Insert a SD Card into the SD card slot of the rear unit.
(2) Start playing back the recorded video.
(3) Press the
PAUSE button to freeze the desired pictures.
(4) Press the
Enter button to save the video in the SD Card.
The quantity of video that can be stored depends on the SD card capacity. The image is stored in the
AVI compressed format. If more than one clip is stored in a SD card, file names will be assigned in
sequence as shown below.
SAVE TO M0000.AVI
SAVE TO M0001.AVI
…
SAVE TO M000N.AVI
NOTE: ●The JPEG file format can be played and deleted in the DVR. Please refer to section 4.4.5.
●The AVI file format can not. It can only be played in a card reader connected to a computer.
●The file format can be selected from “SD FILE” item on Setup Menu. Please refer to section
5.5 for more detail.
3. Backup the System setting info into SD Card.
The MV-DR4000 offers a quick setup method by using a SD card. If a user wants to set many
4CH DVR devices with the same settings, the 4CH DVR could save the whole setting in the SD
card, then transfer it to another DVR. (Approx. 800KB space required on the card)
Save the whole setting into the SD card:
Insert a SD card into the SD card slot.
Press the Setup button to enter the setup mode and select the SYSTEM.
Highlight SYSTEM and press the Enter button to enter the SYSTEM SETTING page.
Set SD SETUP to SAVE. Then the system setting info will auto save into SD card.
Transfer the system setting info of DVR to another:
Insert the SD card containing the stored system setting info into the DVR.
Press the Setup button to enter the setup mode and select the SYSTEM.
Highlight SYSTEM and press the Enter button to enter the SYSTEM SETTING page.
Then set SD SETUP to LOAD.
4. Updating System Software (Please refer to section 3.4 for more details.)
MAIN MENU
RECORD
ALARM/ MOTION
TIMER/ SEQ/ TITLE
COMMUNICATION
DISK
SYSTEM
GOTO SYSTEM SETTING
SYSTEM
OPERATION LOG : ENTER
MENU BACKGND : 2
BUZZER : ON
PASSWORD : SET
SETUP PWD : OFF
DEFAULT : LOAD
SD SETUP : SAVE
VERSION : ENTER
MAIN PAGE
VIEW OPERATION LOG
