68
12.2.2 Enable DHCP Function
Use the “^” and “v” buttons , and , to highlight NET DHCP; select ON. Then
press the
Enter button to proceed.
NOTE: This function can only work if the LAN which the unit is connected to has a DHCP
server. If the DHCP server is working, the DVR will obtain an IP address automatically
from the DHCP server. In that case please skip the section 2.3 (Set IP address) and
follow section 3. (TCP/IP Communication Software).
12.2.3 Set IP Address
You don’t need to set a NET IP for the unit if the LAN which the unit is connected to has a DHCP
server. Otherwise, please follow the instructions given below:
Use the
“^” and “v” buttons , and , to highlight the NET IP. Press the Enter button to
enter the NET IP page
Set the IP, MASK and GATEWAY. Then press the Enter button to proceed. The
following is a sample setting.
IP: 192.168.0.1
MASK: 255.255.255.0
GATEWAY: 0.0.0.0
HTTP PORT: 80
MAIN MENU
RECORD
ALARM/ MOTION
TIMER/ SEQ/ TITLE
COMMUNICATION
DISK
SYSTEM
GOTO COMM PAGE
COMM SETTING
COMM ID : 01
RS232 : ON
RS485 : ON
NET ENABLE : ON
NET DHCP : ON
NET IP : SET
FTP SETTING
MAIN PAGE
SET ETHERNET DHCP
MAIN MENU
RECORD
ALARM/ MOTION
TIMER/ SEQ/ TITLE
COMMUNICATION
DISK
SYSTEM
GOTO COMM PAGE
COMM SETTING
COMM ID : 01
RS232 : ON
RS485 : ON
NET ENABLE : ON
NET DHCP : ON
NET IP : SET
FTP SETTING
MAIN PAGE
SET ETHERNET
