55
9. O.S.D. Message
No. O.S.D. Message Meanings
1 NO DISK No hard-disk detected after power up
2 BATTERY LOW Suggest change the battery and reset the system time
3 LOADING System Boot up
4 VIDEO LOSS Video loss
5 VIDEO IN Video input source
6 KEY LOCKED Key lock function is on
7 KEY UNLOCKED Key lock function is off
8 n1 OF n2 ITEMS PROGRESS n3 % BACKUP n1/n2 NOW
9 BACKUP COMPLETE Backup complete
10 HD2 SPACE NOT ENOUGH HD2 has not enough space for backup
11 NO ENTRY FOR BACKUP No backup is possible.
12 BACKUP INCOMPLETE
Backup incomplete, since the user has pressed the STOP
button to stop it
13 NOT FOUND The system cannot find a video in the Search function.
14 END Playback of recorded video has reached the end point
15 DISK FULL
Hard disks are full; this happens only when the DISK
FULL item in the setup menu is set to STOP.
16 EMPTY
The user presses the PLAY button or uses the SEARCH
function, but no video can be played.
17 SET TO NTSC, PLS RESTART
System has to be set to NTSC, please reboot (PAL is
similar)
18 SOFTWARE UPDATE Software update
19 PLEASE RESTART
The system should be rebooted after the software has
been updated
20 NO DISK
The user has pressed the Save key without putting in a
SD card, or there is a disk error.
21 DATA NOT CONTINUOUS
The system found data in an installed HDD that cannot be
used contiguously. Suggest you remove HD2 from the
system.
22 DISK ATTACHED HD2 has been attached.
23 DISK REMOVED HD2 has been removed.
24 FAN STOPPED The chassis fan has stopped for over 30 seconds.
25 HDn ERROR AT xxxxx
There is a hard-disk error during recording, where n is the
hard-disk number and xxxxx is the hexadecimal location.
26 NOT PRESENT
When the user tries to clear a disk that was not attached
in the setup menu.
27 SAVE TO DISK Start saving to the JPEG file.
28 SAVE TO Fnnn. JPG Save to Fnnn. JPG (where nnn= 0..999)
29 SAVE OK Save to the JEPG is ok.
30 SD CARD WRITE PROTECT A SD card is write-protected; or there is an error
31 WAIT . . .
The composition of the hard disk is changing now. Or, it is
saving the image into the SD card. Please wait for a while.
