5.2 ALARM / MOTION SETTING
This menu allows users to program the configuration of alarm recording only when an alarm input is
activated. The device will record as long as the alarm input is activated.
ALM OPERATION:
This option determines whether to activate/deactivate the alarm recording when it detects an alarm input.
ON: The device activates the alarm recording when it detects an alarm input.
OFF: The device ignores the alarm signal when it detects an alarm input.
REC RATE:
This option is for the purpose of adjusting the number of pictures recorded every second into a storage
disk when an alarm input is activated. For a NTSC unit, there are 5 different record speeds you can
select from:
30F/S (30 frames per second), 15F/S, 10F/S, 6F/S, and REMAIN. For a PAL unit, there
are 5 different record speeds you can select from:
25F/S (25 frames per second), 12.5F/S, 8.3F/S,
5F/S,
and REMAIN. If you select REMAIN for use, the device will record images at the same speed as
set on the
REC page.
REC QUALITY:
This option determines the image quality to be recorded when an alarm input occurs. There are 4
levels of image quality to choose from:
BEST, HIGH, STANDARD, and BASIC. The table below shows
the level of image quality with the corresponding compression ratio and image size for every 4
pictures(CH1 ~ CH4 )
AUDIO:
This option determines the way to record sound if necessary.
ON: Enables AUDIO recording.
OFF: Disables AUDIO recording.
NOTE: Audio function can only be activated in the following refresh rate in NTSC(PAL): 10(8.3),
6(5), 2.7(2.7), 1.2(1.4), 0.61(0.76), 0.35(0.44) frames/sec
Compression Ratio
Image Quality
Best High Standard Basic
Image Size 60KB 50KB 40KB 32KB
MAIN MENU
RECORD
ALARM/ MOTION
TIMER/ SEQ/ TITLE
COMMUNICATION
DISK
SYSTEM
GOTO ALARM / MOTION PAGE
ALARM / MOTION
ALM OPERATION : OFF
REC RATE : 10F/S
REC QUALITY : BEST
AUDIO : OFF
ALM TYPE : NO
ALM DURATION : 0 SEC
PRE- ALARM : OFF
MOTION SETTING
MAIN PAGE
ALARM REC ENABLE
