AXIS M1143–L
Detectors
Detectors
Camera Tampering
Camera Ta m per ing can generate an alarm whenever the camera is repositioned, or when the lens is covered, sprayed or severely
defocused. To send an alarm, for example an email, an action rule must be set up.
To configure tampering:
1. Go to Detectors > Camera Tampering.
2. Set the Minim um duration, t hat is , the time that must elaps e b efore an alarm is generated. This can hel p prevent false
alarms for known conditions that affect the image.
3. Select Alarm for dark images if an alarm should be generated if lights are dimmed or turned off, or if the lens is sprayed,
covered, or rendered severely out of focus.
4. Click Save.
To configure the product to send an alarm when tampering occurs:
1. Go to Events > Action Rules.
2. Click Add to set up a new action rule.
3. Enter a Name for the action ru le.
4. Under Condition,selectDetectors from the Trigger list.
5. Select Tampering from the list of detectors.
6. Optiona lly, select a schedule and set additional conditions.
7. Select the action. To send an email, select Send Notification a
nd select a Re cipient from the list of defined recipients.
Note
The While the rule is active option under Duration cannot be used with camera tampering, since camera tampering does not
have a duration and once it has been triggered it will not automatically return to its untriggered state.
For more information on actions rules, see
Events on page 27
.
Motion Detection
Motion detection is used to generate an alarm w h enever movement starts or stops in the camera view.
Motion detection is configured by defining up to 10 Include and Exclude w ind ows:
• Include windows —define areas where motion should be detected
• Exclude windows —define areas within an Include window that should be ignored (areas outside Include windows
are automatically ig nore d).
For instructions, see
Set Up Motion Detection Windows on page 25
.
To control the number of motion detection alarms, the parameters Object Size, History and Sensitivity can be adjusted. See
Motion Detection Parameters on p age 25
.
Once motion detection windows are configured, the Axis product can be configured to p erform actions w hen motion is detected.
Possible actions include uploading images and start recording. For more information, see
Setting Up an Action Rule on page 28
.
24
