AXIS M1143–L
Recordings
Recordings
TheAxisproductcanbeconfigured to record video continuously or according to an action rule:
• To start a continuous recording, see
page 31
.
• To set up action rule s, see
page 28
.
• To access recordings, see
Recording List on page 31
.
•Toconfigure camera controlled storage, see
Storage on page 41
.
Recording List
Recorded videos are listed on the Recordings > List page. The list shows each recor ding’s start date and time, duration and the
event that triggered the recording.
To play or download a recording, follow these steps:
1. Go to Recordings > List.
2. Use the filter to narrow the lis t of recordings. Enter the desired filter criteria and click Filter. Some filters ma y take
a long time to complete.
3. Select the recording.
4. Click Play to play the recording, or click Download to dow nload the recording.
Multiple recordings can be dow nload ed at the same time. Select the recordings and click Download. The downloaded file is a zip fi le
containing a minimum of three files, of which the Matroska (mkv) filesaretheactualrecordings.The recordings are time-stamped
with the date and time they w ere dow nloaded (tha t is, not the date the
recordings were made).
Note
To play record ings in Windows Media Player, AXIS Matroska File Splitter must be installed. AXIS Matros ka File Splitter
can be downloaded from www.axis.com/techsup/software
For detailed r ecor ding and video information, s e lect a recording and click Properties.
To remove a recording, select the r ecor ding and click Remove.
Continuous Recording
TheAxisproductcanbeconfigured to continuously save video to a storage device. See
Storage on page 41
for more information
about storage devices. To prevent the disk from becoming full, it is recommended to configure the dis k to autom atica lly remove
old recordings.
To start a continuous recording, follow these steps:
1. Go to Recordings > Continuous.
2. Select Enabled.
3. Select type of storage device from the Disk list.
4. Select a Stream profile to use for continuous recordings.
5. Click Save to save and start the recording.
31
